* 1-668-169-11 TRANS BOARD (D890AV/XB55AV/XB88AV)
************
< CONNECTOR >
* CN901 1-564-526-11 PLUG, CONNECTOR 11P
CN903 1-774-108-11 PIN, CONNECTOR (PC BOARD)
< FUSE >
! F902 1-532-505-31 FUSE, TIME-LAG (T5AL/250V) (XB88AV:E,AR)
< RESISTOR >
! R901 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
(D890AV)
! R901 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
(XB55AV/XB88AV)
! R903 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
(D890AV)
! R903 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
(XB55AV/XB88AV)
! R911 1-202-725-00 SOLID 3.3M 10% 1/2W
(D890AV)
< SWITCH >
! S901 1-762-753-11 SWITCH, VOLTAGE SELECTION (XB88AV:E,AR)
< TRANSFORMER >
! T901 1-431-639-11 TRANSFORMER, POWER (XB55AV/XB88AV)
! T901 1-431-671-11 TRANSFORMER, POWER (D890AV)
**************************************************************
MISCELLANEOUS
**************
1 1-769-974-11 WIRE (FLAT TYPE) (13 CORE)
(D890AV/XB55AV/XB88AV)
1 1-773-006-11 WIRE (FLAT TYPE) (15 CORE) (XB80AV)
5 1-233-544-11 ENCAPSULATED COMPONENT (D890AV)
5 1-233-545-11 ENCAPSULATED COMPONENT (XB55AV/XB88AV)
58 1-773-163-11 WIRE (FLAT TYPE) (21 CORE)
59 1-769-949-11 WIRE (FLAT TYPE) (11 CORE)
120 1-773-051-11 WIRE (FLAT TYPE) (17 CORE)
! 152 1-569-008-11 ADAPTOR, CONVERSION 2P (XB88AV:AR)
! 152 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (XB80AV:UK)
156 1-782-715-11 WIRE (FLAT TYPE) (19 CORE)
* 357 1-452-879-11 MAGNET (CDM37L-5BD29AL)
* 357 1-452-925-11 MAGNET ASSY (CDM37LH-5BD29AL)
! 401 8-820-020-02 OPTICAL PICK-UP KSS-213D/Q-NP
402 1-769-069-11 WIRE (FLAT TYPE)(16 CORE)
! CNP901 1-558-943-41 CORD, POWER (XB88AV:E)
! CNP901 1-558-943-51 CORD, POWER (XB88AV:MX)
! CNP901 1-575-042-21 CORD, POWER (D890AV)
! CNP901 1-575-651-21 CORD, POWER (XB80AV/XB88AV:AR,SAF)
! CNP901 1-696-845-11 CORD, POWER (XB55AV/XB88AV:AUS)
FL601 1-517-617-11 INDICATOR TUBE, FLUORESCENT
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Sony Corporation
Home A&V Products Company
98C0976-1
Printed in Japan © 1998. 3
Published by General Engineering Dept.
(Shibaura)
HCD-D890AV/XB55AV/XB80AV/XB88AV
9-922-785-11
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
TRANS
HP101 1-500-093-11 HEAD, MAGNETIC (PLAYBACK)
HRPE101 1-500-094-11 HEAD, MAGNETIC (REC/PB/ERASE)
M1 X-3371-223-1 MOTOR ASSY (CAPSTAN)
M2 A-2004-410-A MOTOR ASSY (TRIGGER)
M201 A-4660-977-A MOTOR ASSY (TABLE)
M101 X-4917-523-4 MOTOR ASSY (SPINDLE)
M102 X-4917-504-1 MOTOR ASSY (SLED)
M901 1-698-792-11 FAN, DC
! T501 1-431-139-11 TRANSFORMER, POWER (XB80AV)
! T901 1-431-639-11 TRANSFORMER, POWER (XB55AV/XB88AV)
! T901 1-431-671-11 TRANSFORMER, POWER (D890AV)
**************************************************************
*************
HARDWARE LIST
*************
#1 7-621-255-15 SCREW +P 2X3
#2 7-621-775-00 SCREW +B 2.6X3
#3 7-621-775-10 SCREW +B 2.6X4
#4 7-623-921-01 RING, RETAINING, CAPSTAN
#5 7-685-131-19 SCREW +BTP 2.6X4 TYPE2 N-S
#6 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S
#7 7-685-534-19 SCREW +BTP 2.6X8 TYPE2 N-S
#8 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#9 7-685-862-09 SCREW +BVTT 2.6X8 (S)
#10 7-685-871-01 SCREW +BVTT 3X6 (S)
#11 7-685-872-09 SCREW +BVTT 3X8 (S)
#12 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
#13 7-685-881-09 SCREW +BVTT 4X8 (S)
#14 7-626-301-31 SPRING PIN 2X10
