Sony HCD-DR8AV - Exploded Views - Front Panel (Part 1); Front Panel Section 1 Exploded View

— 108 —
FL601
Supplied with
J803
not supplied
Supplied with
J801
63
63
64
not supplied
not supplied
not supplied
#3
#3
not supplied
Supplied with
RV850
51
53
61
62
54
55
52
57
65
59
60
56
65
65
65
65
65
65
65
65
65
65
65
65
58
8-2. FRONT PANEL SECTION 1
51 4-214-716-01 KNOB (VOL)
* 52 1-672-193-11 TC-A BOARD
* 53 1-672-194-11 TC-B BOARD
* 54 1-672-190-12 FRONT INPUT BOARD
* 55 A-4417-530-A JACK BOARD, COMPLETE
* 56 A-4417-491-A FL BOARD, COMPLETE (W900AV)
* 56 A-4426-287-A FL BOARD, COMPLETE (DR8AV)
* 57 A-4417-548-A PANEL VR BOARD, COMPLET
58 4-948-236-21 CUSHION (107)
59 4-214-717-01 CURSOR
60 4-214-756-01 KNOB (MICROPHONE)
61 1-773-002-11 WIRE (FLAT TYPE) (15 CORE)(80mm)
62 1-773-034-11 WIRE (FLAT TYPE) (15 CORE)(420mm)
* 63 4-949-935-81 CUSHION (FL)
* 64 4-214-749-01 HOLDER (925), FL TUBE
65 4-951-620-01 SCREW (2.6X8), +BVTP
FL601 1-517-839-11 INDICATOR TUBE, FLUORESCENT
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
