Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 129 —
! R806 1-216-436-00 METAL OXIDE 3.9K 5% 1W F
! R807 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R808 1-220-893-11 METAL PLATE 0.22 10% 5W F
R809 1-260-076-11 CARBON 10 5% 1/2W
R810 1-249-437-11 CARBON 47K 5% 1/4W
R811 1-249-417-11 CARBON 1K 5% 1/4W F
R812 1-249-431-11 CARBON 15K 5% 1/4W
R813 1-249-441-11 CARBON 100K 5% 1/4W
R814 1-249-421-11 CARBON 2.2K 5% 1/4W F
R815 1-247-863-91 CARBON 22K 5% 1/4W
R816 1-249-429-11 CARBON 10K 5% 1/4W
R817 1-249-421-11 CARBON 2.2K 5% 1/4W F
R818 1-249-417-11 CARBON 1K 5% 1/4W F
R819 1-249-439-11 CARBON 68K 5% 1/4W
! R820 1-202-972-61 FUSIBLE 1 5% 1/4W F
R822 1-247-863-91 CARBON 22K 5% 1/4W
R823 1-247-863-91 CARBON 22K 5% 1/4W
R824 1-249-416-11 CARBON 820 5% 1/4W F
(DR8AV)
R824 1-249-418-11 CARBON 1.2K 5% 1/4W F
(W900AV)
! R825 1-215-891-11 METAL OXIDE 680 5% 2W F
R827 1-249-441-11 CARBON 100K 5% 1/4W
R828 1-247-903-00 CARBON 1M 5% 1/4W
R831 1-249-441-11 CARBON 100K 5% 1/4W
R832 1-249-441-11 CARBON 100K 5% 1/4W
R833 1-249-419-11 CARBON 1.5K 5% 1/4W F
R834 1-249-429-11 CARBON 10K 5% 1/4W
R835 1-249-437-11 CARBON 47K 5% 1/4W
R836 1-249-417-11 CARBON 1K 5% 1/4W F
R837 1-249-435-11 CARBON 33K 5% 1/4W
R838 1-249-435-11 CARBON 33K 5% 1/4W
! R839 1-215-877-11 METAL OXIDE 22K 5% 1W F
R840 1-249-402-11 CARBON 56 5% 1/4W F
! R842 1-202-972-61 FUSIBLE 1 5% 1/4W F
R851 1-249-417-11 CARBON 1K 5% 1/4W F
R852 1-249-437-11 CARBON 47K 5% 1/4W
R853 1-249-415-11 CARBON 680 5% 1/4W F
! R855 1-215-891-11 METAL OXIDE 680 5% 2W F
! R857 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R858 1-220-893-11 METAL PLATE 0.22 10% 5W F
R859 1-260-076-11 CARBON 10 5% 1/2W
R860 1-249-437-11 CARBON 47K 5% 1/4W
R861 1-249-417-11 CARBON 1K 5% 1/4W F
R862 1-249-431-11 CARBON 15K 5% 1/4W
R863 1-249-441-11 CARBON 100K 5% 1/4W
R864 1-249-425-11 CARBON 4.7K 5% 1/4W F
(W900AV)
R865 1-247-863-91 CARBON 22K 5% 1/4W
(W900AV)
R868 1-249-417-11 CARBON 1K 5% 1/4W F
R880 1-249-402-11 CARBON 56 5% 1/4W F
! R889 1-215-877-11 METAL OXIDE 22K 5% 1W F
R901 1-247-855-91 CARBON 10K 5% 1/4W
(W900AV)
R902 1-249-441-11 CARBON 100K 5% 1/4W
(W900AV)
! R902 1-215-916-00 METAL OXIDE 680 5% 3W F
(DE8AV)
R903 1-249-429-11 CARBON 10K 5% 1/4W
R904 1-249-417-11 CARBON 1K 5% 1/4W F
R905 1-249-429-11 CARBON 10K 5% 1/4W
R906 1-247-807-31 CARBON 100 5% 1/4W
R907 1-247-807-31 CARBON 100 5% 1/4W
R908 1-247-807-31 CARBON 100 5% 1/4W
(W900AV)
R909 1-247-791-91 CARBON 22 5% 1/4W
(DR8AV)
R911 1-247-855-91 CARBON 10K 5% 1/4W
(W900AV)
R912 1-247-855-91 CARBON 10K 5% 1/4W
(W900AV)
< RELAY >
RY401 1-755-168-11 RELAY
RY402 1-515-920-11 RELAY (24V)
RY403 1-515-920-11 RELAY (24V)
< TERMINAL >
TM401 1-537-842-11 TERMINAL BOARD (FRONT SPEAKER)
TM402 1-537-510-31 TERMINAL BOARD (SPEAKER) (6P)
(SURROUND SPEAKER)
************************************************************
* A-4417-548-A PANEL-VR BOARD, COMPLETE
*************************
< CAPACITOR >
C610 1-162-306-11 CERAMIC 0.01uF 20% 16V
C611 1-162-306-11 CERAMIC 0.01uF 20% 16V
C612 1-164-159-21 CERAMIC 0.1uF 50V
< CONNECTOR >
CN701 1-784-776-11 CONNECTOR, FFC 15P
< LED >
D611 8-719-058-04 LED SEL5223S-TP15 (GROOVE)
D612 8-719-058-04 LED SEL5223S-TP15 (SUPER WOOFER)
D613 8-719-057-97 LED SEL5923A-TP15 (PROLOGIC)
D614 8-719-057-97 LED SEL5923A-TP15 (DVD 5.1CH)
D616 8-719-058-04 LED SEL5223S-TP15 (ENTER)
D617 8-719-058-04 LED SEL5223S-TP15 (DSP)
D618 8-719-058-04 LED SEL5223S-TP15 (EFFECT)
D619 8-719-075-54 LED SLR-325YCT31-NP (MENU 2)
D620 8-719-075-54 LED SLR-325YCT31-NP (MENU 1)
D621 8-719-075-54 LED SLR-325YCT31-NP (P. FILE)
D623 8-719-075-54 LED SLR-325YCT31-NP (FILE 5)
D624 8-719-075-54 LED SLR-325YCT31-NP (FILE 4)
D625 8-719-075-54 LED SLR-325YCT31-NP (FILE 3)
D626 8-719-075-54 LED SLR-325YCT31-NP (FILE 2)
D627 8-719-075-54 LED SLR-325YCT31-NP (FILE 1)
< RESISTOR >
R761 1-249-410-11 CARBON 270 5% 1/4W F
R762 1-249-411-11 CARBON 330 5% 1/4W
R763 1-249-413-11 CARBON 470 5% 1/4W F
R764 1-249-414-11 CARBON 560 5% 1/4W F
R765 1-249-415-11 CARBON 680 5% 1/4W F
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
PA PANEL-VR
