Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 132 —
* 1-673-110-11 TRANS BOARD (DR8AV)
************
* 1-672-431-11 TRANS BOARD (W900AV)
************
1-533-233-21 HOLDER,FUSE
7-685-646-11 SCREW+BVTP 3 × 8 TYPE2
< CAPACITOR >
C843 1-130-777-00 FILM 0.1uF 10% 100V
C893 1-130-777-00 FILM 0.1uF 10% 100V
C961 1-162-306-11 CERAMIC 0.01uF 20% 16V
C963 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
* CN901 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P (DR8AV)
* CN952 1-564-526-11 PLUG,CONNECTOR 11P (W900AV)
* CN952 1-564-528-11 PLUG, CONNECTOR 13P (DR8AV)
< DIODE >
D832 8-719-510-68 DIODE D5SBA204101 (W900AV)
D832 8-719-060-53 DIODE RBV-2506 (DR8AV)
< FUSE >
! F951 1-532-504-31 FUSE (T4AL/250V) (DR8AV:E,EA,AR,SP)
! F961 1-532-506-31 FUSE (T6.3AL/250V)
! F962 1-532-506-31 FUSE (T6.3AL/250V)
! F963 1-532-505-31 FUSE (T5AL/250V)
! F964 1-532-505-31 FUSE (T5AL/250V)
< RESISTOR >
! R951 1-219-121-11 FUSIBLE 0.22 5% 1/4W F
(DR8AV)
! R951 1-219-122-81 FUSIBLE 0.33 5% 1/4W F
(W900AV)
! R952 1-219-121-11 FUSIBLE 0.22 5% 1/4W F
(DR8AV)
! R952 1-219-122-81 FUSIBLE 0.33 5% 1/4W F
(W900AV)
! R953 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
R961 1-219-237-11 SOLID 3.3M 20% 1/2W
(W900AV:US)
R961 1-202-725-11 SOLID 3.3M 10% 1/2W
(W900AV:CND)
< TRANSFORMER >
! T951 1-433-612-11 TRANSFORMER, POWER (W900AV)
! T951 1-433-613-11 TRANSFORMER, POWER (DR8AV)
< SWITCH >
! VS901 1-771-291-11 SWITCH, POWER (VOLTAGE SELECTOR)
(DR8AV:E,EA,AR,SP)
************************************************************
MISCELLANEOUS
**************
1 1-769-977-11 WIRE (FLAT TYPE) (13 CORE)
5 1-233-545-11 TUNER (FM/AM) (DRV8AV:EA,AR,SP,AUS)
5 1-693-445-11 TUNER (FM/AM) (W900AV)
5 1-693-453-11 TUNER (FM/AM) (DR8AV:E)
61 1-773-002-11 WIRE (FLAT TYPE) (15 CORE) (80mm)
62 1-773-034-11 WIRE (FLAT TYPE) (15 CORE) (420mm)
! 152 1-569-008-21 ADAPTOR, CONVERSION 2P (EA,SP)
156 1-790-287-11 WIRE (FLAT TYPE) (19 CORE)
160 1-773-006-11 WIRE (FLAT TYPE) (15 CORE)
161 1-773-056-11 WIRE (FLAT TYPE) (17 CORE)
459 A-2004-629-A MECHANICAL BLOCK ASSY (230AWR2)
459 A-2004-630-A MECHANICAL BLOCK ASSY (230PWR2)
503 A-4660-978-A GEAR (PULLEY) ASSY
507 1-452-925-21 MAGNET ASSY
510 X-4947-960-1 ROLLER ASSY
! 601 8-820-020-02 OPTICAL PICK-UP KSS-213D/Q-NP
602 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
! CNP901 1-558-943-41 CORD, POWER (E,MX)
! CNP901 1-575-042-21 CORD, POWER (CND)
! CNP901 1-575-651-21 CORD, POWER (EA, SP)
! CNP901 1-783-531-31 CORD, POWER (US)
! CNP901 1-783-941-31 CORD, POWER (MX,AR)
! CNP901 1-696-845-11 CORD, POWER (AUS)
FL601 1-517-839-11 INDICATOR TUBE, FLUORESCENT
HP101 A-2056-681-B DECK (A) ASSY, HEAD (230AWR2)
HP101 A-2056-683-B DECK (A) ASSY, HEAD (230PWR2)
HRPE101 A-2056-682-B DECK (B) ASSY, HEAD (230AWR2)
HRPE101 A-2056-684-B DECK (B) ASSY, HEAD (230PWR2)
M1 A-2004-628-A MOTOR ASSY, CAPSTAN
M101 X-4917-523-3 MOTOR ASSY (SPINDLE)
M102 X-4917-504-1 MOTOR ASSY (SLED)
M201 A-4660-977-A MOTOR ASSY (TABLE)
M901 1-698-792-11 FAN, DC (DR8AV)
! T951 1-433-612-11 TRANSFORMER, POWER (W900AV)
! T951 1-433-613-11 TRANSFORMER, POWER (DR8AV)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-871-01 SCREW +BVTT 3 × 6 (S)
#2 7-685-872-09 SCREW +BVTT 3 × 8 (S)
#3 7-685-646-79 SCREW +BVTP 3 × 8 TYPE2 N-S
#4 7-685-534-14 SCREW +BTP 2.6 × 8 TYPE2 N-S
#5 7-685-553-19 SCREW +BTP 2.6 × 6 TYPE2 N-S
#6 7-685-105-19 TPG +P 2 × 8 TYPE2 NON-SLIT
#7 7-685-650-79 SCREW +BVTP 3 × 16 TYPE2 IT-3
#8 7-685-881-09 SCREW +BVTT 4 × 8 (S)
#9 7-685-853-04 SCREW +BVTT 2 × 6 (S)
#10 7-685-850-04 SCREW +BVTT 2 × 3 (S)
#11 7-685-851-04 SCREW +BVTT 2 × 4 (S)
#12 7-628-254-15 SCREW +PS 2.6 × 6
#13 7-628-254-50 SCREW +PS 2.6 × 16
TRANS
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés
par une marque ! sont cri-
tiques pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
HCD-DR8AV/W900AV
Ver 1.1 2003.05
