HCD-DZ100
3-2. CASE, FRONT PANEL ASSY
Note: Follow the disassembly procedure in the numerical order given.
DVD lid
1
The lever is moved in the direction
of the arrow with the thin rod.
2
3
DVD lid
4
screw (CASE3 TP2)
5
screw
(CASE3 TP2)
6
five screws (+BV 3)
7
case
qs
front panel assy
8
three screws (+BV 3)
qa
w
ire (flat type)
19core (CN509)
0
claw
9
claw
w
w
w
.
