HCD-DZ100
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
6-4. DVD MECHANISM DECK SECTION (CDM85-DVBU102)
501 A-6071-669-A LOADING ASSY (M)
502 3-088-371-01 BELT
503 4-974-725-11 SCREW (M1.7X2.5), P
504 4-674-137-11 SCREW (PTP2X5)
505 3-088-372-01 INSULATOR
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
not
supplied
501
504
502
503
505
505
505
505
506
507
508
506
506
506
506 3-087-599-01 INSULATOR SCREW
0 507 8-820-290-02 DEVICE, OPTICAL KHM-310CAA/C2RP
508 1-830-687-51 WIRE (FLAT TYPE) (24 CORE)
