Sony HCD-DZ100 - Printed Wiring Boards; Main Board (Side A) Layout

3636
HCD-DZ100
HCD-DZ100
5-13. PRINTED WIRING BOARD – MAIN BOARD (SIDE A) –
• See page 23 for Circuit Boards Location.
• Semiconductor
Location
Ref. No. Location
D503 H-4
D914 F-8
D915 F-8
D923 H-8
D925 H-8
D932 D-7
IC101 D-5
IC102 D-5
IC103 D-4
IC104 D-4
IC105 D-3
IC106 D-2
IC108 E-5
IC109 E-4
IC110 E-3
IC303 D-6
IC305 E-5
IC503 E-2
IC509 H-3
IC511 H-4
Q506 H-4
Q507 G-3
Q943 D-7
Q947 D-7
:Uses unleaded solder.
12
A
B
C
D
E
G
H
F
34567 9
8
DMB11
BOARD
CN4501
(Page 29)
A
I/O BOARD
CN601
(Page 47)
F
DMB11
BOARD
CN302
(Page 29)
C
for PROGRAM WRITER
E
EXCEPT AEP,UK
EXCEPT SP
E
1
3
4
5
1
3
4
5
E
E
IC106 IC105 IC104 IC103
IC109
IC110
IC509
IC511
IC102
IC108
IC305
IC303
IC101
DMB11
BOARD
CN106
(Page 29)
D
22
C119
CN505
1
11
2
10
1
7
2
6
CN503
C110
R501
IC503
R639
R656
R592
R593
R716
