5
HCD-DZ100
• SERVICE POSITION (DMB11 BOARD)
When servicing side B of the DMB11 board
Remove the DMB11 board from bracket.
(Refer to DISASSEMBLY 3-6. (page 13)).
Set the DMB11 board facing the side B upward as shown.
Connect the cable and make the repair work.
DMB11 board (side B)
DMB bracket
