HCD-DZ100
Pin No. Pin Name I/O Description
93 MODEL I Model select input
94 KEY2 I Key input 2 input
95 KEY1 I Key input 1 input
96 VSS — Ground
97 KEY0 I Key input 0 input
98 VREF I Reference Voltage (+3.3V)
99 VCC I Power supply (+3.3V)
100 M-ST/WMUTE O Selector (IC503) WMUTE signal output
