71
HCD-DZ100
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R816 1-216-809-11 METAL CHIP 100 5% 1/10W
R817 1-216-821-11 METAL CHIP 1K 5% 1/10W
R819 1-216-805-11 METAL CHIP 47 5% 1/10W
R820 1-216-845-11 METAL CHIP 100K 5% 1/10W
R821 1-216-864-11 SHORT CHIP 0
R822 1-216-864-11 SHORT CHIP 0
< SWITCH >
S800 1-418-632-11 ENCODER, ROTARY (VOLUME)
< TRANSFORMER >
T801 1-443-645-11 TRANSFORMER, DC CONVERTER
************************************************************
A-1107-216-A I/O BOARD, COMPLETE (AEP, UK)
A-1114-356-A I/O BOARD, COMPLETE (RU)
A-1121-675-A I/O BOARD, COMPLETE (EXCEPT AEP, UK, RU)
*******************
< CAPACITOR >
C102 1-126-933-11 ELECT 100uF 20% 16V
C103 1-104-662-91 ELECT 22uF 20% 25V
C104 1-104-662-91 ELECT 22uF 20% 25V
C109 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C200 1-216-864-11 SHORT CHIP 0 (EXCEPT AEP, UK, RU)
C201 1-126-964-11 ELECT 10uF 20% 50V
C202 1-115-156-11 CERAMIC CHIP 1uF 10V
C203 1-115-156-11 CERAMIC CHIP 1uF 10V
C204 1-115-156-11 CERAMIC CHIP 1uF 10V
C205 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(EXCEPT AEP, UK, RU)
C206 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(AEP, UK, RU)
C207 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT AEP, UK, RU)
C208 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(EXCEPT AEP, UK, RU)
C209 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C210 1-126-925-91 ELECT 470uF 20% 10V
C211 1-126-933-11 ELECT 100uF 20% 16V
(AEP, UK, RU)
C212 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C213 1-126-933-11 ELECT 100uF 20% 16V
C214 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C215 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(AEP, UK, RU)
C216 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(AEP, UK, RU)
C217 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(AEP, UK, RU)
C218 1-104-662-91 ELECT 22uF 20% 25V
(AEP, UK, RU)
C219 1-104-662-91 ELECT 22uF 20% 25V
(AEP, UK, RU)
C223 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(EXCEPT AEP, UK, RU)
C224 1-126-916-11 ELECT 1000uF 20% 6.3V
(EXCEPT AEP, UK, RU)
C225 1-126-916-11 ELECT 1000uF 20% 6.3V
C226 1-126-916-11 ELECT 1000uF 20% 6.3V
C227 1-126-916-11 ELECT 1000uF 20% 6.3V
(AEP, UK, RU)
C227 1-126-933-11 ELECT 100uF 20% 16V
(EXCEPT AEP, UK, RU)
C228 1-126-916-11 ELECT 1000uF 20% 6.3V
(AEP, UK, RU)
C228 1-126-933-11 ELECT 100uF 20% 16V
(EXCEPT AEP, UK, RU)
C242 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(EXCEPT AEP, UK, RU)
C603 1-126-933-11 ELECT 100uF 20% 16V
C604 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C606 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C607 1-104-662-91 ELECT 22uF 20% 25V
C608 1-126-933-11 ELECT 100uF 20% 16V
C609 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C610 1-104-662-91 ELECT 22uF 20% 25V
C611 1-104-662-91 ELECT 22uF 20% 25V
(EXCEPT AEP, UK, RU)
C612 1-104-662-91 ELECT 22uF 20% 25V
(EXCEPT AEP, UK, RU)
C624 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(EXCEPT AEP, UK, RU)
C625 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(EXCEPT AEP, UK, RU)
C626 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(EXCEPT AEP, UK, RU)
C629 1-126-960-11 ELECT 1uF 20% 50V
C630 1-126-960-11 ELECT 1uF 20% 50V
C632 1-104-662-91 ELECT 22uF 20% 25V
< CONNECTOR >
CN101 1-568-828-11 CONNECTOR, FFC 9P (EXCEPT AEP, UK)
CN101 1-816-955-11 CONNECTOR, FFC/FPC 11P (AEP, UK)
CN201 1-779-281-11 CONNECTOR, FFC (LIF (NON-ZIF)) 13P
CN601 1-779-291-11 CONNECTOR, FFC (LIF (NON-ZIF)) 23P
< DIODE >
D200 8-719-988-61 DIODE 1SS355TE-17 (AEP, UK, RU)
D206 8-719-988-61 DIODE 1SS355TE-17 (AEP, UK, RU)
< IC >
IC201 6-705-602-01 IC MM1623BFBE
IC602 8-759-385-76 IC MC14052 BDR2
IC603 8-759-649-89 IC MC4558CD
< JACK >
J200 1-764-593-21 JACK 2P (SAT) (EXCEPT AEP, UK, RU)
J201 1-780-211-11 TERMINAL BOARD (S TERMINAL+1P)
(MONITOR OUT)
(EXCEPT AEP, UK, RU)
J202 1-817-449-11 JACK, PIN 3P (COMPONENT VIDEO OUT)
(EXCEPT AEP, UK, RU)
J203 1-815-911-11 CONNECTOR, SQUARE TYPE 21P (EURO AV)
(AEP, UK, RU)
< COIL >
L101 1-469-525-91 INDUCTOR 10uH
L201 1-469-525-91 INDUCTOR 10uH
L602 1-469-525-91 INDUCTOR 10uH
FL I/O
