77
HCD-DZ100
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
L302 1-412-939-11 INDUCTOR 1uH
L303 1-216-295-91 SHORT CHIP 0
L931 1-457-058-11 INDUCTOR 10.8uH
L941 1-414-398-11 INDUCTOR 10uH
L942 1-414-398-11 INDUCTOR 10uH
L945 1-414-398-11 INDUCTOR 10uH
L947 1-414-398-11 INDUCTOR 10uH
L948 1-414-398-11 INDUCTOR 10uH
L951 1-414-398-11 INDUCTOR 10uH
< LINE FILTER >
0 LF901 1-457-054-11 LINE FILTER COIL (US, CND, MX, E32)
0 LF901 1-457-079-11 LINE FILTER COIL (EXCEPT US, CND, MX, E32)
< PHOTO COUPLER >
0 PC901 6-600-438-01 IC TLP421F (D4-GR)
0 PC902 6-600-438-01 IC TLP421F (D4-GR)
0 PC903 6-600-438-01 IC TLP421F (D4-GR)
< TRANSISTOR >
Q101 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q102 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q103 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q104 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q105 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q106 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q107 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q108 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q109 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q110 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q111 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q112 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q301 8-729-120-28 TRANSISTOR 2SC3052EF-T1-LEF
Q302 8-729-120-28 TRANSISTOR 2SC3052EF-T1-LEF
Q303 6-550-702-01 TRANSISTOR 2SC3243-TP-E
Q304 8-729-120-28 TRANSISTOR 2SC3052EF-T1-LEF
Q506 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q507 8-729-027-23 TRANSISTOR RT1P141C-TP-1
0 Q901 8-729-140-04 TRANSISTOR 2SB1116A-TP-LK
0 Q921 8-729-142-51 TRANSISTOR 2SD1616A-TP-LK
Q943 1-801-806-11 TRANSISTOR RT1N441C-TP-1
Q945 6-550-718-01 TRANSISTOR RSR025N03TL
Q947 1-801-806-11 TRANSISTOR RT1N441C-TP-1
< RESISTOR >
R108 1-216-837-11 METAL CHIP 22K 5% 1/10W
R109 1-216-837-11 METAL CHIP 22K 5% 1/10W
R110 1-216-837-11 METAL CHIP 22K 5% 1/10W
R111 1-216-837-11 METAL CHIP 22K 5% 1/10W
R112 1-216-837-11 METAL CHIP 22K 5% 1/10W
R113 1-216-837-11 METAL CHIP 22K 5% 1/10W
R114 1-216-837-11 METAL CHIP 22K 5% 1/10W
R115 1-216-837-11 METAL CHIP 22K 5% 1/10W
R116 1-216-837-11 METAL CHIP 22K 5% 1/10W
R117 1-216-837-11 METAL CHIP 22K 5% 1/10W
R118 1-216-837-11 METAL CHIP 22K 5% 1/10W
R119 1-216-837-11 METAL CHIP 22K 5% 1/10W
R131 1-216-864-11 SHORT CHIP 0
R132 1-216-864-11 SHORT CHIP 0
R133 1-216-864-11 SHORT CHIP 0
R134 1-216-864-11 SHORT CHIP 0
R135 1-216-864-11 SHORT CHIP 0
R136 1-216-864-11 SHORT CHIP 0
R139 1-216-864-11 SHORT CHIP 0
R141 1-216-864-11 SHORT CHIP 0
R142 1-216-864-11 SHORT CHIP 0
R143 1-216-864-11 SHORT CHIP 0
R144 1-216-864-11 SHORT CHIP 0
R145 1-216-864-11 SHORT CHIP 0
R146 1-216-864-11 SHORT CHIP 0
R151 1-216-864-11 SHORT CHIP 0
R152 1-216-864-11 SHORT CHIP 0
R153 1-216-864-11 SHORT CHIP 0
R154 1-216-864-11 SHORT CHIP 0
R155 1-216-864-11 SHORT CHIP 0
R156 1-216-864-11 SHORT CHIP 0
R161 1-216-864-11 SHORT CHIP 0
R162 1-216-864-11 SHORT CHIP 0
R163 1-216-864-11 SHORT CHIP 0
R164 1-216-864-11 SHORT CHIP 0
R165 1-216-864-11 SHORT CHIP 0
R166 1-216-864-11 SHORT CHIP 0
R171 1-216-864-11 SHORT CHIP 0
R172 1-216-864-11 SHORT CHIP 0
R173 1-216-864-11 SHORT CHIP 0
R174 1-216-864-11 SHORT CHIP 0
R175 1-216-864-11 SHORT CHIP 0
R176 1-216-864-11 SHORT CHIP 0
R191 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R192 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R193 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R194 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R195 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R196 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R201 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R202 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R203 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R204 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R205 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R206 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R211 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R212 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R213 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R214 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R215 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R216 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R221 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R222 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R223 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R224 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R225 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R226 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R241 1-216-809-11 METAL CHIP 100 5% 1/10W
R242 1-216-809-11 METAL CHIP 100 5% 1/10W
R243 1-216-809-11 METAL CHIP 100 5% 1/10W
MAIN
Ver. 1.2
