Sony HCD-ECL77BT - Printed Wiring Board - TUNER Board

HCD-ECL77BT/ECL99BT
37
5-19. PRINTED WIRING BOARD - TUNER Board -
TUNER BOARD (COMPONENT SIDE)
TUNER BOARD (CONDUCTOR SIDE)
A
1 2 3 4
TUNER BOARD (COMPONENT SIDE)
TUNER BOARD (CONDUCTOR SIDE)
B
C
D
E
(ECL99BT: US, CND)
(ECL77BT: AEP, UK, E2, E4, E51, E93, MX, BR, AR/ECL99BT: UK, E2, E4, E51, E93, MX, AR, RU)
• : Uses unleaded solder.
• See page 20 for Circuit Boards Location.
