HCD-ECL77BT/ECL99BT
6-2. REAR PANEL SECTION
51 4-475-812-01 CD DOOR
52 A-2059-261-A TUNER BOARD, COMPLETE (WITH HARNESS)
(US, CND)
52 A-1970-504-A TUNER BOARD, COMPLETE (WITH HARNESS)
(Except US, CND, AEP, UK)
52 A-1981-801-A TUNER BOARD, COMPLETE (WITH HARNESS)
(AEP, UK)
53 4-475-943-01 FAN SCREW 5X8 (ECL99BT)
54 4-488-729-01 SCREW (3X6)
FAN1 9-885-189-67 FAN (ECL99BT)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
front panel section
MAIN board section
51
not supplied
not supplied
FAN1
F
D
B
D
B
E
E
C
C
C
52
54
54
54
54
54
53
53
52
54
54
(ECL99BT)
(US, CND)
(Except
US, CND)
F
