Sony HCD-ECL77BT - Side Cover, Top Cover Assy

HCD-ECL77BT/ECL99BT
8
Note: Follow the disassembly procedure in the numerical order given.
2-2. SIDE COVER, TOP COVER ASSY
3
3
6 Remove the top cover assy
in the direction of the arrow.
7 top cover assy
2 five claws
2 two claws
2 five claws
4 right side cover
4 left side cover
5 four claws
2 two claws
2 two claws
2 two claws
1 rear screw
(black 3 u 8)
1 rear screw
(black 3 u 8)
1 rear screw
(black 3 u 8)
1 rear screw
(black 3 u 8)
1 rear screw
(black 3 u 8)
1 rear screw
(black 3 u 8)
