Sony HCD-ECL77BT - Page 6

HCD-ECL77BT/ECL99BT
6
HOW TO EJECT THE DISC WHEN POWER SWITCH TURN OFF
3 Pull out the disc tray.
1 Refer to “SECTION 2. DISASSEMBLY” (page 7), remove the side cover,
the top cover assy and the rear panel block from the unit.
– Rear view –
2 Turn the traverse gear
in the direction of the
arrow.
top side
– Rear bottom view –
