10
HCD-EP313
3-6. Cassette Door Assy
3-7. MAIN Board, POWER Board
1
two claws
2
cassette door assy
7
two cushions
4
PT PWB cover
2
screw
(+BVTP 3
×
8)
5
four screws
(+BVTP 4
×
12)
6
shield plate trans
3
MAIN board
8
POWER board
1
connector
6p (CN901)
