Sony HCD-EP313 - CD Mechanism Deck (KSM-213 EDP); Optical Pick-up (KSS-213 E;C2 N)

11
HCD-EP313
2 two screws
(+PWH 2.6
× 10)
9 screw
(+P 2
× 5)
7 two cushion
rubbers
8 four remove soldrings.
6 two cushion
rubbers
3 two screws
(+PWH 2.6
× 10)
1 CD deck cover
4 three claws
5 panel CD
qa CD board
qs CD mechanism deck
(KSM-213EDP)
q; w ire (flat type)
16p (CN102)
2 gear (A)
1 claw
5 sled shaft
6 KSS-213E/C2N
4
3
3-8. CD Mechanism Deck (KSM-213EDP)
3-9. Optical Pick-up (KSS-213E/C2N)
