HCD-EP313
6-7. Printed Wiring Board – CONTROL Section (COMPONENT SIDE) –
• See page 16 for Circuit Boards Location.
IC303
X
?/1
x
m
M
.>
VOLUME
PLAY MODE
TUNER
MD
CD
BASS/TRE
DSG
LIQUID CRYSTAL DISPLAY
(STANDBY)
DISPLAY
B
TO CD BOARD
CN101
(Page 18)
CONTROL BOARD
(COMPONENT SIDE)
BACK LIGHT BOARD
1-688-569
1-688-568
A
TO MAIN BOARD
CN202
(Page 20)
12
A
E
D
C
B
3456 8
7
Ref. No. Location
D301 D-5
D302 E-6
D303 D-6
D304 E-5
D305 E-6
D306 D-7
D307 D-5
D308 E-5
IC303 B-6
Q303 D-6
• Semiconductor
Location
