Sony HCD-EP313 - Printed Wiring Board - MAIN Section (COMPONENT SIDE)

2020
HCD-EP313
6-4. Printed Wiring Board – MAIN Section (COMPONENT SIDE) –
• See page 16 for Circuit Boards Location.
IC800
IC204
IC200
TO
DECK BLOCK
(HEAD)
J202
PHONES
TO
DECK BLOCK
(MOTOR)
J203
SPEAKER
IMPEDANCE
USE 6-16Ω
J201
MD
L
R
(TO TUNER UNIT)
ANTENNA
TO
(CD DOOR)
1
2
4
5
9
11
10
8
76
3
1-688-567
MAIN BOARD
(COMPONENT SIDE)
L
R
C
TO
TRANSFORMER
BOARD
CN901
(Page 26)
A
TO CONTROL
BOARD
CN302
(Page 23)
12
A
E
D
C
B
F
G
H
3456 8
7910
Ref. No. Location
D200 H-4
D201 H-6
D202 G-7
D203 H-6
D204 G-7
D205 G-6
D206 G-7
D207 F-6
D209 C-2
D210 C-2
D211 E-6
D212 H-6
D213 H-6
D403 F-6
D404 F-6
D405 F-5
D501 C-7
D602 C-5
D603 C-5
D801 F-4
D802 D-9
D803 F-3
D804 D-8
IC200 G-6
IC204 H-4
IC800 F-4
Q205 C-4
Q206 B-4
Q402 F-6
Q404 F-6
Q405 F-6
Q406 F-5
Q451 D-6
Q453 D-7
Q454 D-7
Q502 F-6
• Semiconductor
Location
