Sony HCD-EP313 - Page 31

31
HCD-EP313
Pin No.
70
71
72
73
74
75
76
77
78
79
80
I/O
O
O
O
I
I
I
I
O
O
O
O
Pin Name
O-XLAT
O-CDON
O-SQCK
I-SENS
I-STEREO
I-IFC
I-TUNE
O-PLLCE
O-PLLCLK
O-MADATA
O-DATA
Description
Latch signal output to the CD unit
CD power supply control signal output
SUBQ clock output to the CD unit
SENS signal input from the CD unit
Stereo/mono detection signal input from the tuner
Data input from the tuner
Tuner tuned status signal input
Tuner chip enable signal output to the tuner
Clock signal output to the tuner
Data output to the tuner
Data output to the CD unit
