Sony HCD-EX1 - Power Supply Capacitors List

45
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
A-4426-744-A POWER BOARD, COMPLETE (US,CND)
***********************
A-4426-753-A POWER BOARD, COMPLETE (EXCEPT US,CND)
***********************
1-533-293-11 FUSE HOLDER
< CAPACITOR >
C1 1-107-956-11 ELECT 220uF 20% 200V
(US,CND)
C1 1-131-714-11 ELECT 100uF 20% 400V
(EXCEPT US,CND)
C2 1-107-888-11 ELECT 47uF 20% 25V
C3 1-130-477-00 MYLAR 0.0033uF 5% 50V
C4 1-107-429-11 CERAMIC 0.0022uF 10% 1KV
C5 1-162-290-31 CERAMIC 470PF 10% 50V
C6 1-131-983-11 FILM 0.1uF 275V
C7 1-131-983-11 FILM 0.1uF 275V
C9 1-113-907-51 CERAMIC 0.0022uF 99% 250V
C10 1-131-984-51 CERAMIC 330PF 2KV
C11 1-113-920-11 CERAMIC 0.0022uF 20% 250V
C12 1-113-920-11 CERAMIC 0.0022uF 20% 250V
C13 1-131-714-11 ELECT 100uF 20% 400V
(EXCEPT US,CND)
C14 1-113-920-11 CERAMIC 0.0022uF 20% 250V
C21 1-164-159-21 CERAMIC 0.1uF 50V
C901 1-107-425-11 CERAMIC 470PF 10% 1KV
C902 1-131-969-31 ELECT 1800uF 25V
C903 1-131-970-31 ELECT 1500uF 25V
C911 1-107-425-11 CERAMIC 470PF 10% 1KV
C912 1-131-969-31 ELECT 1800uF 25V
C913 1-131-970-31 ELECT 1500uF 25V
C931 1-107-425-11 CERAMIC 470PF 10% 1KV
C932 1-126-768-11 ELECT 2200uF 20% 16V
C939 1-124-995-11 ELECT 220uF 20% 10V
C941 1-107-425-11 CERAMIC 470PF 10% 1KV
C942 1-126-012-11 ELECT 470uF 20% 16V
C949 1-124-995-11 ELECT 220uF 20% 10V
C951 1-136-153-00 FILM 0.01uF 5% 50V
C952 1-162-292-31 CERAMIC 680PF 10% 50V
< CONNECTOR >
* CN1 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
CN903 1-764-334-11 PLUG, CONNECTOR 11P
< DIODE >
D2 8-719-200-93 DIODE 11EQS10-TA2
D3 8-719-200-93 DIODE 11EQS10-TA2
D4 8-719-210-21 DIODE 11EQS04-NTA2B
D6 8-719-109-97 DIODE MTZJ-T-77-6.8B
D7 8-719-911-19 DIODE 1SS133T-72
D10 8-719-077-64 DIODE 11E4N-TA1B2
D11 8-719-077-64 DIODE 11E4N-TA1B2
D12 8-719-077-64 DIODE 11E4N-TA1B2
D13 8-719-077-64 DIODE 11E4N-TA1B2
D21 8-719-048-55 DIODE MTZJ-T-77-10C
D22 8-719-110-53 DIODE MTZJ-T-77-20C
D901 8-719-043-52 DIODE F5KQ60
D911 8-719-043-52 DIODE F5KQ60
D931 8-719-210-21 DIODE 11EQS04-NTA2B
D941 8-719-210-21 DIODE 11EQS04-NTA2B
< GROUND TERMINAL >
EPT1 1-537-770-21 TERMINAL BOARD, GROUND
EPT2 1-537-770-21 TERMINAL BOARD, GROUND (US,CND)
EPT901 1-537-770-21 TERMINAL BOARD, GROUND
< FUSE >
! F1 1-532-465-31 FUSE (T3.15AL/250V)(EXCEPT US,CND)
! F1 1-533-690-11 FUSE GLASS (3.15AL/125V)(US,CND)
< FERRITE BEAD >
FB1 1-412-473-21 INDUCTOR 0UH
< IC >
IC1 8-749-016-64 IC STR-F6674-LF1352
IC933 8-759-288-53 IC LA5617
IC951 8-749-016-65 IC SE015N
< COIL >
L1 1-419-341-11 COIL, COMMON MODE CHOKE
L901 1-419-281-11 INDUCTOR 10uH
L911 1-419-281-11 INDUCTOR 10uH
< ISOLATER >
PC1 8-749-013-68 IC PS2561-1-D
PC2 8-749-013-68 IC PS2561-1-D
< TRANSISTOR >
Q21 8-729-111-29 TRANSISTOR 2SD1616-TP-LK
Q22 8-729-118-00 TRANSISTOR 2SB1116-TP-LK
Q23 8-729-119-76 TRANSISTOR 2SA1115TP-EF
Q951 8-729-620-05 TRANSISTOR 2SC2603TP-EF
< RESISTOR >
! R1 1-202-725-00 SOLID 3.3M 10% 1/2W
(US,CND)
R2 1-249-426-11 CARBON 5.6K 5% 1/4W
R3 1-249-421-11 CARBON 2.2K 5% 1/4W F
R4 1-249-415-11 CARBON 680 5% 1/4W F
! R5 1-217-151-00 METAL 0.22 10% 2W
R8 1-249-393-11 CARBON 10 5% 1/4W F
! R9 1-215-903-11 METAL OXIDE 68K 5% 2W F
R10 1-247-895-91 CARBON 470K 5% 1/4W
R11 1-247-863-91 CARBON 22K 5% 1/4W
R21 1-249-425-11 CARBON 4.7K 5% 1/4W F
R22 1-249-424-11 CARBON 3.9K 5% 1/4W F
R23 1-247-881-00 CARBON 120K 5% 1/4W
R24 1-249-439-11 CARBON 68K 5% 1/4W
! R939 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
! R949 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
R951 1-249-419-11 CARBON 1.5K 5% 1/4W F
R952 1-249-401-11 CARBON 47 5% 1/4W F
POWER
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
