46
Sony Corporation
Home Audio Company
9-929-017-11
99H0988-1
Printed in Japan © 1999. 8
Published by Quality Assurance Dept.
HCD-EX1
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R953 1-249-420-11 CARBON 1.8K 5% 1/4W F
R954 1-249-437-11 CARBON 47K 5% 1/4W
R955 1-249-425-11 CARBON 4.7K 5% 1/4W F
R956 1-249-415-11 CARBON 680 5% 1/4W F
< TRANSFORMER >
! T901 1-435-130-11 TRANSFORMER, POWER
< THERMISTOR >
! TH1 1-803-806-31 THERMISTOR, NTC
**************************************************************
1-675-407-11 REG BOARD
**********
< CAPACITOR >
C933 1-164-346-11 CERAMIC CHIP 1uF 16V
C934 1-126-926-11 ELECT 1000uF 20% 10V
C935 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C936 1-126-964-11 ELECT 10uF 20% 50V
C937 1-126-926-11 ELECT 1000uF 20% 10V
C961 1-126-967-11 ELECT 47uF 20% 50V
C962 1-164-159-21 CERAMIC 0.1uF 50V
C963 1-136-153-00 FILM 0.01uF 5% 50V
< CONNECTOR >
* CN901 1-568-832-11 SOCKET, CONNECTOR 13P
< DIODE >
D933 8-719-988-61 DIODE 1SS355TE-17
D934 8-719-200-82 DIODE 11ES2-TA2B
D961 8-719-986-26 DIODE HZS12A3LTA
< IC >
IC931 8-759-460-76 IC BA07FP-E2
IC932 8-759-231-53 IC M5F7805L
< TRANSISTOR >
Q961 8-729-026-68 TRANSISTOR 2SD2525(TP)
Q962 8-729-202-67 TRANSISTOR 2SK246GR3-TPE2
Q964 8-729-120-28 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R961 1-216-073-00 METAL CHIP 10K 5% 1/10W
R962 1-216-049-91 RES,CHIP 1K 5% 1/10W
< TERMINAL >
TM801 1-537-238-11 TERMINAL BOARD
**************************************************************
1-674-909-11 SW BOARD
**********
< SWITCH >
S351 1-571-300-21 SWITCH, ROTARY
**************************************************************
MISCELLANEOUS
*************
9 1-769-889-11 WIRE(FLAT TYPE) (7 CORE)
! 60 1-575-651-21 CORD,POWER (AEP,UK)
! 60 1-783-531-31 CORD,POWER (US,CND)
62 1-791-698-11 WIRE (FLAT TYPE) (16 CORE)
63 1-769-973-11 WIRE (FLAT TYPE) (13 CORE)
64 1-693-407-13 TUNER (US,CND)
64 1-693-408-12 TUNER (EXCEPT US,CND)
! 65 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK)
! 153 8-820-087-11 OPTICAL PICK-UP KSS-770A/S-N1
155 1-763-381-11 MOTOR, DC
158 1-960-065-11 HARNESS
160 1-791-698-11 WIRE (FLAT TYPE) (16 CORE)
**************************************************************
*************
HARDWARE LIST
*************
#1 7-685-870-01 SCREW +BVTT 3X5 (S)
#2 7-685-246-14 SCREW +KTP 3X8 TYPE2 NON-SLIT
#3 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#4 7-621-775-08 SCREW +B 2.6X3
#5 7-685-534-14 SCREW +BTP 2.6X8 TYPE2 N-S
#6 7-685-132-19 SCREW +P 2.6X5 TYPE2 NON-SLIT
#7 7-624-105-04 STOP RING 2.3, TYPE -E
POWER
SW
REG
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
