43
HCD-EX200
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
MAIN
R553 1-216-089-91 RES-CHIP 47K 5% 1/10W
R554 1-216-025-11 RES-CHIP 100 5% 1/10W
R555 1-216-049-11 RES-CHIP 1K 5% 1/10W
R701 1-216-109-00 METAL CHIP 330K 5% 1/10W
R702 1-216-097-11 RES-CHIP 100K 5% 1/10W
R703 1-216-097-11 RES-CHIP 100K 5% 1/10W
R704 1-216-089-91 RES-CHIP 47K 5% 1/10W
R705 1-216-085-91 RES-CHIP 33K 5% 1/10W
R706 1-216-073-91 RES-CHIP 10K 5% 1/10W
R707 1-216-073-91 RES-CHIP 10K 5% 1/10W
R708 1-216-073-91 RES-CHIP 10K 5% 1/10W
R709 1-216-073-91 RES-CHIP 10K 5% 1/10W
R710 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R751 1-216-025-11 RES-CHIP 100 5% 1/10W
R752 1-216-049-11 RES-CHIP 1K 5% 1/10W
R753 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R754 1-216-089-91 RES-CHIP 47K 5% 1/10W
R755 1-216-089-91 RES-CHIP 47K 5% 1/10W
R756 1-216-073-91 RES-CHIP 10K 5% 1/10W
R757 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R774 1-216-073-00 RES-CHIP 10K 5% 1/10W
R775 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R776 1-216-073-91 RES-CHIP 10K 5% 1/10W
R777 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R778 1-216-037-00 METAL CHIP 330 5% 1/10W
R785 1-216-049-11 RES-CHIP 1K 5% 1/10W
R792 1-216-097-11 RES-CHIP 100K 5% 1/10W
R793 1-216-097-11 RES-CHIP 100K 5% 1/10W
R794 1-216-097-11 RES-CHIP 100K 5% 1/10W
< VIBRATOR >
X361 1-579-280-31 VIBRATOR, CRYSTAL (16.9344MHz)
X701 1-579-233-11 VIBRATOR, CERAMIC (5MHz)
X702 1-567-098-41 VIBRATOR, CRYSTAL (32KHz)
*******************************************************
1-682-069-11 PANEL BOARD
***********
< CAPACITOR >
C606 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C611 1-124-589-11 ELECT 47uF 20% 16V
C612 1-124-589-11 ELECT 47uF 20% 16V
C613 1-163-038-91 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
* CN601 1-568-850-11 SOCKET, CONNECTOR 7P
* CN602 1-568-941-11 PIN, CONNECTOR 3P
< DIODE >
D621 8-719-056-11 DIODE SML72423C-TP15 (`/1)
< IC >
IC601 8-742-129-00 IC SBX1971-51P
< TRANSISTOR >
Q622 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q623 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q651 8-729-900-53 TRANSISTOR DTC114EK
Q652 8-729-900-53 TRANSISTOR DTC114EK
< RESISTOR >
R601 1-216-041-00 METAL CHIP 470 5% 1/10W
R602 1-216-045-00 METAL CHIP 680 5% 1/10W
R603 1-216-049-11 RES-CHIP 1K 5% 1/10W
R606 1-216-017-91 RES-CHIP 47 5% 1/10W
R609 1-216-061-91 RES-CHIP 3.3K 5% 1/10W
R611 1-216-041-00 METAL CHIP 470 5% 1/10W
R612 1-216-045-00 METAL CHIP 680 5% 1/10W
R613 1-216-049-11 RES-CHIP 1K 5% 1/10W
R614 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R615 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R616 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R619 1-216-061-91 RES-CHIP 3.3K 5% 1/10W
R622 1-216-041-00 METAL CHIP 470 5% 1/10W
R623 1-216-037-00 METAL CHIP 330 5% 1/10W
< SWITCH >
S601 1-771-410-21 SWITCH, TACTILE (`/1)
S602 1-571-532-21 SWITCH, TACTILE (DISPLAY)
S603 1-771-410-21 SWITCH, TACTILE (FUNCTION)
S604 1-771-410-21 SWITCH, TACTILE (TUNER/BAND)
S611 1-771-410-21 SWITCH, TACTILE (u)
S612 1-771-410-21 SWITCH, TACTILE (x)
S613 1-771-410-21 SWITCH, TACTILE (TUNING -.m)
S614 1-771-410-21 SWITCH, TACTILE (TUNING +M >)
S615 1-771-410-21 SWITCH, TACTILE (VOL -)
S616 1-771-410-21 SWITCH, TACTILE (VOL +)
< TEST PIN >
TP603 1-690-880-51 LEAD (WITH CONNECTOR)
******************************************************
A-4725-964-A POWER BOARD, COMPLETE
********************
1-533-293-11 FUSE HOLDER
4-224-739-01 CASE (TR), RUBBER
4-224-742-01 TUBE, RUBBER
4-224-743-01 RETAINER, IC
7-685-132-19 SCREW +P 2.6X5 TYPE2 NON-SLIT
< CAPACITOR >
0C1 1-107-956-11 ELECT 220uF 20% 200V
0C2 1-107-888-11 ELECT 47uF 20% 25V
0C3 1-130-477-00 MYLAR 0.0033uF 5% 50V
0C4 1-107-429-11 CERAMIC 0.0022uF 10% 1KV
0C5 1-162-290-31 CERAMIC 470PF 10% 50V
0C6 1-131-983-11 FILM 0.1uF 10% 275V
0C7 1-131-983-11 FILM 0.1uF 10% 275V
0C9 1-113-907-51 CERAMIC 0.0022uF 99% 250V
0C10 1-162-115-00 CERAMIC 330PF 10% 2KV
0C11 1-113-920-11 CERAMIC 0.0022uF 20% 250V
0C12 1-113-920-11 CERAMIC 0.0022uF 20% 250V
0C14 1-113-920-11 CERAMIC 0.0022uF 20% 250V
0C21 1-164-159-11 CERAMIC 0.1uF 50V
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
