44
HCD-EX200
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
POWER
C901 1-107-425-11 CERAMIC 470PF 10% 1KV
C902 1-131-969-11 ELECT 1800uF 20% 25V
C903 1-131-970-11 ELECT 1500uF 20% 25V
C904 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C905 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C911 1-107-425-11 CERAMIC 470PF 10% 1KV
C912 1-131-969-11 ELECT 1800uF 20% 25V
C913 1-131-970-11 ELECT 1500uF 20% 25V
C914 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C915 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C931 1-107-425-11 CERAMIC 470PF 10% 1KV
C932 1-126-768-11 ELECT 2200uF 20% 16V
C939 1-124-995-11 ELECT 220uF 20% 10V
C940 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C941 1-107-425-11 CERAMIC 470PF 10% 1KV
C942 1-126-012-11 ELECT 470uF 20% 16V
C949 1-124-995-11 ELECT 220uF 20% 10V
C950 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C951 1-136-153-00 FILM 0.01uF 5% 50V
C952 1-162-292-31 CERAMIC 680PF 10% 50V
< CONNECTOR >
* CN1 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
CN903 1-764-334-11 PLUG, CONNECTOR 11P
< DIODE >
0D2 8-719-200-93 DIODE 11EQS10-TA2
0D3 8-719-200-93 DIODE 11EQS10-TA2
0D4 8-719-210-21 DIODE 11EQS04
0D6 8-719-109-97 DIODE RD6.8ESB2
0D7 8-719-911-19 DIODE 1SS119-25
0D10 8-719-084-21 DIODE 10E6N-TA1B2
0D11 8-719-084-21 DIODE 10E6N-TA1B2
0D12 8-719-084-21 DIODE 10E6N-TA1B2
0D13 8-719-084-21 DIODE 10E6N-TA1B2
0D21 8-719-048-55 DIODE MTZJ-T-77-10C
0D22 8-719-110-53 DIODE RD20ESB2
D901 8-719-043-52 DIODE F5KQ60
D911 8-719-043-52 DIODE F5KQ60
D931 8-719-210-21 DIODE 11EQS04
D941 8-719-210-21 DIODE 11EQS04
D951 8-719-911-19 DIODE 1SS119-25
D952 8-719-911-19 DIODE 1SS119-25
D953 8-719-200-93 DIODE 11EQS10-TA2
< GROUND TERMINAL >
EPT1 1-537-770-21 TERMINAL BOARD, GROUND
EPT2 1-537-770-21 TERMINAL BOARD, GROUND
EPT901 1-537-770-21 TERMINAL BOARD, GROUND
< FUSE >
0F1 1-533-451-11 FUSE, GLASS TUBE (DIA. 5) (3.15A/125V)
< FERRITE BEAD >
0FB1 1-412-473-21 INDUCTOR 0uH
< IC >
0IC1 8-749-019-48 IC STR-F6676-LF1352
IC933 8-759-288-53 IC LA5617
IC951 8-749-016-65 IC SE015N
< COIL >
0L1 1-419-528-11 INDUCTOR 13mH
L901 1-419-281-11 INDUCTOR 10uH
L911 1-419-281-11 INDUCTOR 10uH
< ISOLATER >
0PC1 8-749-013-68 IC PS2561-1-D
0PC2 8-749-013-68 IC PS2561-1-D
< TRANSISTOR >
0Q21 8-729-111-29 TRANSISTOR 2SD1616A-K
0Q22 8-729-140-04 TRANSISTOR 2SB1116A-L
0Q23 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q951 8-729-620-05 TRANSISTOR 2SC2603-EF
< RESISTOR >
0R1 1-219-237-11 SOLID 3.3M 20% 1/2W
0R2 1-249-426-11 CARBON 5.6K 5% 1/4W
0R3 1-247-843-11 CARBON 3.3K 5% 1/4W
0R4 1-249-415-11 CARBON 680 5% 1/4W
0R5 1-217-151-00 METAL 0.22 10% 2W
0R8 1-249-393-11 CARBON 10 5% 1/4W
0R9 1-215-903-11 METAL OXIDE 68K 5% 2W
0R10 1-247-895-00 CARBON 470K 5% 1/4W
0R11 1-249-433-11 CARBON 22K 5% 1/4W
0R21 1-249-425-11 CARBON 4.7K 5% 1/4W
0R22 1-249-424-11 CARBON 3.9K 5% 1/4W
0R23 1-247-881-00 CARBON 120K 5% 1/4W
0R24 1-249-439-11 CARBON 68K 5% 1/4W
0R939 1-219-119-81 FUSIBLE 0.1 5% 1/4W
0R949 1-219-119-81 FUSIBLE 0.1 5% 1/4W
R951 1-249-419-11 CARBON 1.5K 5% 1/4W
R952 1-249-401-11 CARBON 47 5% 1/4W
R953 1-249-420-11 CARBON 1.8K 5% 1/4W
R954 1-249-437-11 CARBON 47K 5% 1/4W
R955 1-249-425-11 CARBON 4.7K 5% 1/4W
R956 1-249-415-11 CARBON 680 5% 1/4W
< TRANSFORMER >
0T901 1-435-130-11 TRANSFORMER, POWER
< THERMISTOR >
0TH1 1-803-806-31 THERMISTOR, NTC
******************************************************
A-4725-969-A REG BOARD, COMPLETE
******************
< CAPACITOR >
C891 1-164-159-11 CERAMIC 0.1uF 50V
C892 1-164-159-11 CERAMIC 0.1uF 50V
REG
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
