HCD-EX200
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C893 1-164-159-11 CERAMIC 0.1uF 50V
C894 1-164-159-11 CERAMIC 0.1uF 50V
C895 1-164-159-11 CERAMIC 0.1uF 50V
C896 1-164-159-11 CERAMIC 0.1uF 50V
C933 1-164-346-11 CERAMIC CHIP 1uF 16V
C934 1-126-926-11 ELECT 1000uF 20% 10V
C935 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C936 1-126-964-11 ELECT 10uF 20% 50V
C937 1-126-926-11 ELECT 1000uF 20% 10V
C961 1-126-967-11 ELECT 47uF 20% 50V
C962 1-164-159-11 CERAMIC 0.1uF 50V
C963 1-126-967-11 ELECT 47uF 20% 50V
< CONNECTOR >
* CN901 1-568-832-11 SOCKET, CONNECTOR 13P
< DIODE >
D933 8-719-988-61 DIODE 1SS355TE-17
D934 8-719-200-82 DIODE 11ES2
D961 8-719-986-26 DIODE HZS12A3LTA
< IC >
IC931 8-759-460-76 IC BA07FP-E2
IC932 8-759-231-53 IC M5F7805L
< TRANSISTOR >
Q961 8-729-026-68 TRANSISTOR 2SD2525(TP)
Q962 8-729-202-67 TRANSISTOR 2SK246-GR3
Q963 8-729-900-53 TRANSISTOR DTC114EK
Q964 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R891 1-249-393-11 CARBON 10 5% 1/4W
R892 1-249-393-11 CARBON 10 5% 1/4W
R961 1-216-073-91 RES-CHIP 10K 5% 1/10W
R962 1-216-049-11 RES-CHIP 1K 5% 1/10W
R963 1-249-417-11 CARBON 1K 5% 1/4W
< TERMINAL >
TM801 1-537-238-11 TERMINAL BOARD
******************************************************
1-682-073-11 SW BOARD
********
< SWITCH >
S351 1-786-154-11 SWITCH, ROTARY (OPEN/CLOSE)
******************************************************
MISCELLANEOUS
*************
15 1-769-889-11 WIRE (FLAT TYPE) (7 CORE)
11 1-754-208-11 ANTENNA, FM
060 1-783-531-31 CORD, POWER
62 1-791-698-11 WIRE (FLAT TYPE) (16 CORE)
63 1-769-973-11 WIRE (FLAT TYPE) (13 CORE)
64 1-693-407-13 TUNER
127 1-769-973-11 WIRE (FLAT TYPE) (13 CORE)
0132 A-4909-346-A BASE UNIT (KSM-770ACA)
LCD701 1-804-474-11 DISPLAY PANEL, LIQUID CRYSTAL
M351 X-4952-498-1 MOTOR ASSY
***********************************************************************************
************
HARDWARE LIST
************
#1 7-685-870-01 SCREW +BVTT 3X5 (S)
#2 7-685-246-14 SCREW +KTP 3X8 TYPE2 NON-SLIT
#3 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#4 7-621-775-08 SCREW +B 2.6X3
#5 7-685-534-14 SCREW +BTP 2.6X8 TYPE2 N-S
#8 7-627-554-28 SCREW, PRECISION +P 2X5 TYPE1
#9 7-623-205-22 SW2, TYPE2
