Sony HCD-HP8V - CD Mechanism Deck (CDM69 BH-30 BD62); JACK Board, VMP Board

12
HCD-HP8V
3-7. CD Mechanism Deck (CDM69BH-30BD62)
3-8. JACK Board, VMP Board
5 four screws
(BVTP3 × 8 )
7 CD mechanism deck
(CDM69BH-30BD62)
2 two screws
(BVTP3 × 8 )
1 two screws
(BVTP3 × 8 )
6 w ire (flat type)
28p (CN101)
4 w ire (flat type)
19p (CN201)
3 blacket (TR
)
2 screw
(BVTP3 × 8
)
6 support spacer (VMP)
4 two screws
(BVTP3 × 8 )
1 connector
(CN301)
3 JACK board
7 VMP board
5
