HCD-HP8V
SECTION 2
GENERAL
This section is extracted
from instruction manual.
Main unit
CD SYNC 9 (18)
DIMMER ws (25)
DISC 1 – 5 qs (10, 13, 32)
Disc slot qf
DISPLAY 6 (24, 25, 32)
Display window 3
ECHO LEVEL qg (21)
FUNCTION wd (9, 11, 13, 16, 18,
19, 28)
GROOVE w; (20)
MIC jack qj
MIC LEVEL qh (21)
PHONES jack qd
PLAY MODE 7 (9, 13, 18, 19,
23)
PRESET EQ wa (20)
PRESET/ALBUM +/– wf (10,
13, 15, 16)
REC PAUSE/START 0 (18, 19,
21)
Remote sensor 2
REPEAT 8 (12)
Tape deck 4
TUNER/BAND 5 (15, 16)
TUNING +/– qa (15, 16)
VOLUME ql (22)
?/1 (power) 1 (7, 8, 16, 22, 23,
32)
m/M (rewind/fast forward)
qa (10, 18)
./> (go back/go forward)
qa (7, 10, 12, 13, 18)
x (stop) 5 (10, 11, 16, 18, 19,
21, 23, 32)
X (pause) 5 (7, 10, 18)
CD N (play) 5 (10, 11, 13, 14,
37)
TAPE nN (play) 5 (18, 19,
23)
DISC 1 Z – DISC 5 Z (eject) qk
(9, 10)
List of button locations and reference pages
How to use this page
Use this page to find the location of buttons and other
parts of the system that are mentioned in the text.
