Sony HCD-HP8V - Printed Wiring Boards - BD Section

3333
HCD-HP8V
8-2. Printed Wiring Boards — BD Section — • See page 28 for Circuit Boards Location.
IC102
IC103
30 16
115
M
(SPINDLE)
(COMPONENT SIDE)
BD BOARD
(CONDUCTOR SIDE)
BD BOARD
E
D101
E
OPTICAL
PICK-UP
BLOCK
(A-MAX. 3)
M
(SLED)
TP68
(FE)
TP70
(TE)
TP72
(RFAC)
TP71
(RFDC)
TP73
(DVC)
J
VMP
BOARD
CN101
(Page 35)
1-684-174-
12
(12)
1-684-174-
12
(12)
12
A
B
C
D
E
34567
8
• Semiconductor
Location
Ref. No. Location
D101 C-6
IC102 B-7
IC103 D-6
Q101 D-6
Q102 B-6
