Sony HCD-HP8V - Base Unit Section (BU-30 BD62)

67
HCD-HP8V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
9-11. Base Unit Section (BU-30BD62)
601
602
604
605
604
605
604
605
604
605
606
607
603
610
601 4-243-716-01 HOLDER (BU-30)
602 4-244-556-01 SPRING (FRONT), COMPRESSION
603 A-4728-371-A BD BOARD, COMPLETE
604 4-231-451-01 INSULATOR (BU-30)
605 4-985-672-01 SCREW (+PTPWH M2.6), FLOATING
606 1-782-817-11 WIRE (FLAT TYPE)(16 CORE)
0 607 A-4735-189-A BU-30 (61) ASSY (including M101, M102)
610 4-227-045-31 SPRING (INSULATOR), COIL
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
