Sony HCD-HP8V - Page 52

52
HCD-HP8V
Pin No. Pin Name I/O Description
1VBO
Connected to ground via a capacitor
2IREF O
D/A converter reference current output
3 VRF I
D/A converter reference voltage input
4VGO
Connected to the analog power supply (+2.5V) via a capacitor
5 XCPSIG O
Luminance video composite/component signal invert output terminal Not used
6 CPSIG O
Luminance video composite/component signal output
7NCO
Chrominance video composite signal output Not used
8V AVD2 —
Analog power supply terminal (+2.5V) (for D/A converter)
9V AVS2 —
Analog ground terminal (for D/A converter)
10 IVD1 —
Power supply terminal (+3.3V) (for I/O)
11 I2C CLK I/O
Communication data reading clock signal input or transfer clock signal output terminal
Not used
12 I2C DATA I/O
Communication data bus terminal Not used
13 GPIO0 I
Serial data input from the system controller
14 GPIO1 O
Serial data output to the system controller
15 GPIO2 O
Serial data transfer clock signal output to the system controller
16 GPIO3 I
Request signal input from the system controller
17 LVD1 —
Digital power supply terminal (+2.5V) (for AV decoder block)
18 GPIO4 I
Acknowledge signal input from the system controller
19 GPIO5 O
Chip select signal output to the system controller
20, 21 GPIO6, GPIO7 I/O
Not used
22 LVS1 —
Digital ground terminal (for AV decoder block)
23 GPIO8 I/O
Not used
24 GPIO9 O
Frequency selection signal output
25 GPIO10 I/O
Not used
26 GPIO11 O
Serial data latch pulse signal output to the digital filter
27 LVD2 —
Digital power supply terminal (+2.5V) (for AV decoder block)
28 GPIO12 O
Control signal output to the D/A converter
29 GPIO13 O
Serial data transfer clock signal output to the digital filter and D/A converter
30 GPIO14 O
Serial data output to the digital filter and D/A converter
31 IVS1 —
Ground terminal (for I/O)
32 LVS2 —
Digital ground terminal (for AV decoder block)
33 IVD2 —
Power supply terminal (+3.3V) (for I/O)
34 to 37
DRADR0 to
DRADR3
O
Address signal output to the D-RAM and program ROM
38 LVD3 —
Digital power supply terminal (+2.5V) (for AV decoder block)
39 to 45
DRADR4 to
DRADR10
O
Address signal output to the D-RAM and program ROM
46 LVS3 —
Digital ground terminal (for AV decoder block)
47 IVS2 —
Ground terminal (for I/O)
48 IVD3 —
Power supply terminal (+3.3V) (for I/O)
49 to 56
DRDAT0 to
DRDAT7
I/O
Two-way data bus with the D-RAM Data input from the program ROM
57 IVS3 —
Ground terminal (for I/O)
58 IVD4 —
Power supply terminal (+3.3V) (for I/O)
• IC505 CXD1887R (DIGITAL SIGNAL PROCESSOR, DIGITAL SERVO PROCESSOR, MPEG VIDEO/AUDIO DECODER,
VIDEO SIGNAL ENCODER)(VMP BOARD)
