HCD-SHAKE33/SHAKE77
19
[HISTORY MODE]
This mode is used to check important data stored in the system
when PROTECTOR happen.
Procedure:
1. During demo mode, press [OPTIONS] button and [FLANGER]
button for 5 seconds to mode into history mode.
2.
Press the [TUNING +/ M >
x
] button or [TUNING Å /
w
. m ] button to check history data stored.
To release from History Mode.
To release from this mode, press [
\/1 ] button.
Protect Type Description:
Error Code Description
E01 The over current condition to MOSFET occurs
by defect of MOSFET or defect of PS output
line.
E03 Defect of power supply circuit to AMP.
There is possibility of unusual power supply of
any of the AMP IC or Pre-ampli
fi er.
E04 DC appears in SP terminal by defect of AMP
IC and MOSFET
or
Defect of DC FAN and DC FAN driver circuit
E05 Unusual heat up of MOSFET by improper
assembly of heat sink, destruction of MOSFET
etc.
If speaker does not have output even if the set status is not in
PROTECT mode, the following defect might be possible:
Defects Possible cause
RESET defect Reset signal status from micom is not ‘H’.
Display on fl uorescent indicator tube Description
PROCOUNT
dd
No of time protector happen (0 ~ 99)
PROTYPE
dddd
Refer to protect type description
T1
ddddd
H
dd
M
Single Power On Time until protector happened
(0~99999 hours, 0~99Min)
T2
ddddd
H
dd
M
Total Power On Time [ no consider protector happen ]
(0~99999 hours, 0~99Min)
FUNC
ddddddd
Input Function during protector happened
VOL
ddd
Volume setting (MIN / 1 - 50 / MAX)
ATT
ddd
Actual attenuation (-87 … 0)
EQ LOW
ddd
Low EQ level (-6 … 0 … +6)
EQ MI D
ddd
Mid EQ level (-6 … 0 … +6)
EQ H I GH
ddd
High EQ level (-6 … 0 … +6)
SURR
ddd
Surround setting (OFF / ON)
DJ
dddddd dd
DJ Effect setting
DJ Mode: OFF/ISOLAT/FLANGE/PAN/WAH
DJ Setting Value: 1~ 40
BAZUCA
ddd
Bass Bazuca setting (OFF / ON)
