HCD-SHAKE7
10
2-6. MOTHERBOARD BOARD
qa bracket, heat sink
0
3 two screws
(+BVTP 3 u 8)
8 three screws
(+BVTP 3 u 8)
8 two screws
(+BVTP 3 u 8)
8 two screws
(+BVTP 3 u 8)
9 MOTHERBOARD board
5 three screws
(+PTPWH 2.6 u L (DIA8.0))
4 bracket, tunnel
7 heat sink
6 thermal sheet
1 CN1002 (9P)
2 CN1 (5P)
