72
HCD-SHAKE7
SECTION 8
ELECTRICAL PARTS LIST
BUTTON_L BOARD
***************
< DIODE >
D2101 6-503-224-02 DI 1L0352V22F3MIT02
D2102 6-503-388-01 DI 1L0352B13F0MIT02
D2103 6-503-224-02 DI 1L0352V22F3MIT02
D2104 6-503-224-02 DI 1L0352V22F3MIT02
D2105 6-503-224-02 DI 1L0352V22F3MIT02
D2106 6-503-224-02 DI 1L0352V22F3MIT02
< JUMPER RESISTOR >
JR2100 1-216-296-11 SHORT CHIP 0
JR2101 1-216-296-11 SHORT CHIP 0
JR2102 1-216-864-11 SHORT CHIP 0
JR2103 1-216-296-11 SHORT CHIP 0
JR2104 1-216-296-11 SHORT CHIP 0
JR2105 1-216-296-11 SHORT CHIP 0
< RESISTOR >
R2101 1-216-819-11 METAL CHIP 680 5% 1/10W
R2102 1-216-810-11 METAL CHIP 120 5% 1/10W
R2103 1-216-807-11 METAL CHIP 68 5% 1/10W
R2104 1-216-839-11 METAL CHIP 33K 5% 1/10W
R2105 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2106 1-216-864-11 SHORT CHIP 0
R2107 1-216-837-11 METAL CHIP 22K 5% 1/10W
R2108 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R2109 1-216-864-11 SHORT CHIP 0
R2110 1-216-835-11 METAL CHIP 15K 5% 1/10W
R2111 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R2112 1-216-864-11 SHORT CHIP 0
R2113 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R2114 1-216-864-11 SHORT CHIP 0
R2115 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R2116 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2117 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R2118 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
< SWITCH >
S2101 1-762-875-21 SWITCH, TACTILE (+/1)
S2102 1-762-875-21 SWITCH, TACTILE
(BLUETOOTH CONNECTION - PAIRING)
S2103 1-762-875-21 SWITCH, TACTILE (BASS BAZUCA)
S2104 1-762-875-21 SWITCH, TACTILE (DJ EFFECT FLANGER)
S2105 1-762-875-21 SWITCH, TACTILE (MUSIC)
S2106 1-762-875-21 SWITCH, TACTILE (DJ EFFECT ISOLATOR)
S2107 1-762-875-21 SWITCH, TACTILE (MOVIE/GAME)
S2108 1-762-875-21 SWITCH, TACTILE (DJ EFFECT SOUND FLASH)
S2109 1-762-875-21 SWITCH, TACTILE (FOOTBALL)
S2110 1-762-875-21 SWITCH, TACTILE (DJ EFFECT PHASER)
S2111 1-762-875-21 SWITCH, TACTILE (NX)
S2112 1-762-875-21 SWITCH, TACTILE (
.m TUNING–)
S2113 1-762-875-21 SWITCH, TACTILE (x)
*************************************************************
BUTTON_R BOARD
***************
< CONNECTOR >
CN2001 1-779-554-21 CONNECTOR, FFC (LIF (NON-ZIF)) 17P
CN2002 1-779-562-21 CONNECTOR, FFC (LIF (NON-ZIF)) 25P
CN2003 1-779-546-11 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
< JUMPER RESISTOR >
JR2000 1-216-864-11 SHORT CHIP 0
JR2001 1-216-296-11 SHORT CHIP 0
JR2002 1-216-296-11 SHORT CHIP 0
JR2003 1-216-296-11 SHORT CHIP 0
JR2004 1-216-296-11 SHORT CHIP 0
JR2005 1-216-296-11 SHORT CHIP 0
JR2006 1-216-296-11 SHORT CHIP 0
JR2007 1-216-296-11 SHORT CHIP 0
JR2008 1-216-864-11 SHORT CHIP 0
JR2009 1-216-296-11 SHORT CHIP 0
JR2010 1-216-296-11 SHORT CHIP 0
JR2011 1-216-296-11 SHORT CHIP 0
JR2012 1-216-296-11 SHORT CHIP 0
JR2013 1-216-296-11 SHORT CHIP 0
JR2014 1-216-296-11 SHORT CHIP 0
JR2015 1-216-296-11 SHORT CHIP 0
JR2016 1-216-864-11 SHORT CHIP 0
JR2017 1-216-296-11 SHORT CHIP 0
JR2018 1-216-296-11 SHORT CHIP 0
JR2019 1-216-296-11 SHORT CHIP 0
JR2020 1-216-296-11 SHORT CHIP 0
JR2021 1-216-296-11 SHORT CHIP 0
JR2022 1-216-296-11 SHORT CHIP 0
JR2023 1-216-296-11 SHORT CHIP 0
JR2024 1-216-296-11 SHORT CHIP 0
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• CAPACITORS
uF: μF
• COILS
uH: μH
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
BUTTON
_
L BUTTON
_
R
• Abbreviation
AR : Argentina model
E2 : 120V AC area in E model
E4 : African model
E51 : Chilean and Peruvian models
EA : Saudi Arabia model
MX : Mexican model
MY : Malaysia model
SAF : South African model
Ver. 1.2
To Next Page
