Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKE7
73
JR2025 1-216-296-11 SHORT CHIP 0
JR2026 1-216-296-11 SHORT CHIP 0
JR2027 1-216-296-11 SHORT CHIP 0
JR2028 1-216-296-11 SHORT CHIP 0
JR2029 1-216-864-11 SHORT CHIP 0
JR2030 1-216-864-11 SHORT CHIP 0
JR2031 1-216-296-11 SHORT CHIP 0
JR2032 1-216-864-11 SHORT CHIP 0
JR2033 1-216-864-11 SHORT CHIP 0
JR2034 1-216-864-11 SHORT CHIP 0
JR2035 1-216-864-11 SHORT CHIP 0
JR2036 1-216-864-11 SHORT CHIP 0
JR2037 1-216-296-11 SHORT CHIP 0
JR2038 1-216-296-11 SHORT CHIP 0
JR2039 1-216-296-11 SHORT CHIP 0
JR2040 1-216-296-11 SHORT CHIP 0
JR2041 1-216-864-11 SHORT CHIP 0
JR2042 1-216-864-11 SHORT CHIP 0
JR2043 1-216-864-11 SHORT CHIP 0
JR2046 1-216-864-11 SHORT CHIP 0
JR2047 1-216-864-11 SHORT CHIP 0
JR2048 1-216-864-11 SHORT CHIP 0
< RESISTOR >
R2001 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R2002 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R2003 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R2004 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R2005 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R2006 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R2007 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2008 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2009 1-216-819-11 METAL CHIP 680 5% 1/10W
R2010 1-216-835-11 METAL CHIP 15K 5% 1/10W
< SWITCH >
S2001 1-762-875-21 SWITCH, TACTILE (
+)
S2002 1-762-875-21 SWITCH, TACTILE (M> TUNING+)
S2003 1-762-875-21 SWITCH, TACTILE (
– )
S2004 1-762-875-21 SWITCH, TACTILE (OPTIONS)
S2005 1-762-875-21 SWITCH, TACTILE (CD)
S2006 1-762-875-21 SWITCH, TACTILE (LED COLOR)
S2007 1-762-875-21 SWITCH, TACTILE (USB/USB SELECT)
S2008 1-762-875-21 SWITCH, TACTILE (LED PATTERN)
S2009 1-762-875-21 SWITCH, TACTILE (TUNER/BAND)
S2010 1-762-875-21 SWITCH, TACTILE (ZOPEN/CLOSE)
S2011 1-762-875-21 SWITCH, TACTILE (AUDIO IN)
*************************************************************
0 A-1920-097-A DISPLAY BOARD, COMPLETE
***********************
< CAPACITOR >
C2401 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C2406 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C2408 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C2409 1-126-786-11 ELECT 47uF 20% 16V
C2412 1-112-723-21 CERAMIC CHIP 0.0047uF 10% 250V
C2413 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C2414 1-126-795-11 ELECT 10uF 20% 50V
C2415 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2416 1-126-786-11 ELECT 47uF 20% 16V
C2417 1-114-326-11 CERAMIC CHIP 0.22uF 10% 25V
C2418 1-114-326-11 CERAMIC CHIP 0.22uF 10% 25V
< CONNECTOR >
CN2401 1-779-546-11 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
< DIODE >
D2401 6-503-775-01 DI CRH02 (T5R, SONY, XM)
D2402 6-503-775-01 DI CRH02 (T5R, SONY, XM)
D2403 6-503-775-01 DI CRH02 (T5R, SONY, XM)
D2404 6-503-775-01 DI CRH02 (T5R, SONY, XM)
D2405 6-502-970-01 DI DZ2J068M0L
< JUMPER RESISTOR >
JR2400 1-216-296-11 SHORT CHIP 0
JR2401 1-216-296-11 SHORT CHIP 0
JR2402 1-216-296-11 SHORT CHIP 0
JR2403 1-216-296-11 SHORT CHIP 0
JR2404 1-216-296-11 SHORT CHIP 0
JR2405 1-216-296-11 SHORT CHIP 0
JR2406 1-216-296-11 SHORT CHIP 0
JR2407 1-216-296-11 SHORT CHIP 0
JR2408 1-216-296-11 SHORT CHIP 0
JR2409 1-216-296-11 SHORT CHIP 0
< COIL >
L2401 1-412-541-21 INDUCTOR 220uH
< FLOURESCENT INDICATOR TUBE >
ND2401 1-483-465-11 VACUUM FLUORESCENT DISPLAY
< TRANSISTOR >
Q2403 6-553-392-01 TR PBSS8110T
Q2404 6-553-392-01 TR PBSS8110T
< RESISTOR >
R2401 1-216-809-11 METAL CHIP 100 5% 1/10W
R2402 1-216-809-11 METAL CHIP 100 5% 1/10W
R2403 1-216-809-11 METAL CHIP 100 5% 1/10W
R2404 1-216-809-11 METAL CHIP 100 5% 1/10W
R2405 1-216-797-11 METAL CHIP 10 5% 1/10W
R2406 1-216-797-11 METAL CHIP 10 5% 1/10W
R2409 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R2410 1-216-839-11 METAL CHIP 33K 5% 1/10W
R2411 1-257-172-91 METAL CHIP 100 5% 1/3W
R2412 1-257-172-91 METAL CHIP 100 5% 1/3W
R2413 1-216-864-11 SHORT CHIP 0
< TRANSFORMER >
T2401 1-697-233-11 DC-DC CONVERTER TRANSFORMER
*************************************************************
MIC BOARD
*********
< CAPACITOR >
C2301 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2302 1-126-956-91 ELECT 0.1uF 20% 50V
DISPLAY MICBUTTON
