Sony HCD-SHAKE7 - System Diagrams and Board Locations; Circuit Board Locations Overview

HCD-SHAKE7
22
SECTION 6
DIAGRAMS
• Circuit Boards Location
MOTHERBOARD board
MS-476 board
SWITCHING REGULATOR (SMG-1800)
BLUETOOTH module
BUTTON_L board
BUTTON_R board
VOLUME board
RGB BAR_L board
RGB BAR_R board
RC-S801/A (WW)
USB board
MIC board
MIC SUPPORT board
DISPLAY board
