HCD-SHAKE7
11
2-7. SWITCHING REGULATOR (SMG-1800)
1 six screws
(+PWH 3 u 8 (SUMITITE))
5 nine screws
(+PWH 3 u 8 (SUMITITE))
2 sub chassis
6 REGULATOR, SWITCHING
(SMG-1800)
7 chassis
3 CN1 (2P)
4
