Optical Block Diagnosis Flow (2/2)
Does laser diode become luminous ? (Visual check) Is output level of RF signal (CN507 6pin) up to standard?
RF Level = 1.05 ±0.45 Vpp Test CD:YEDS-18 Is there no problem with Long term Aging Test (60min)? Confirms that there is no sound skip.
END
No No
Checks JL606 (LD780) signal.
Checks JL602 (LD650) signal.
Does it output 2V when laser become luminous?
Checks circumference circuit of Q605 or Q606. Checks circumference circuit of IC501 LDO1 and LDO2.
The Optical pickup has a problems. Replaces BU.
DISC IN
No
A
Is output level of RF signal (CN507 6pin) up to standard?
RF Level = 1.05 ±0.45 Vpp Test CD:YEDS-18
Replaces BU if it is not up to standard.
No
No
If it is not up to standard, Lens cleaning is performed. The Optical pickup has a problems. Replaces BU.
