Sony HCD-SHAKE7 - Panel and Mechanism Component Removal

HCD-SHAKE7
7
Note: Follow the disassembly procedure in the numerical order given.
2-1. SIDE-L PANEL ASSY, SIDE-R PANEL ASSY, TOP PANEL
1 three screws
(+BVTP 3 u 10)
2 one screw
(+BVTP 3 u 10)
2 one screw
(+BVTP 3 u 10)
7 one screw
(+BVTP 3 u 10)
8 one screw
(+BVTP 3 u 10)
0 one screw
(+BVTP 3 u 8)
qh one screw
(+BVTP 3 u 8)
9 two screws
(+BVTP 3 u 10)
qs panel, side-L assy
qa
qj
qf one screw
(+BVTP 3 u 10)
qg two screws
(+BVTP 3 u 10)
qk panel, side-R assy
qd one screw
(+BVTP 3 u 10)
6 case, top
5 two screws
(+BVTP 3 u 8)
5 four screws
(+BVTP 3 u 8)
5 three screws
(+BVTP 3 u 8)
5 four screws
(+BVTP 3 u 8)
5 four screws
(+BVTP 3 u 8)
4 panel, top
3
B
A
B
A
