Sony HCD-SHAKE7 - Electrical Parts List - Motherboard Capacitors (Continued); Motherboard Capacitor List (Part 3)

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKE7
77
C794 1-112-777-11 CERAMIC CHIP 0.01uF 10% 25V
C795 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C796 1-112-777-11 CERAMIC CHIP 0.01uF 10% 25V
C797 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C798 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C799 1-128-390-11 ELECT CHIP 220uF 20% 6.3V
C800 1-128-996-11 ELECT CHIP 4.7uF 20% 50V
C801 1-128-996-11 ELECT CHIP 4.7uF 20% 50V
C802 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C803 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C804 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C805 1-124-779-00 ELECT CHIP 10uF 20% 16V
C806 1-124-779-00 ELECT CHIP 10uF 20% 16V
C902 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C904 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C907 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
C908 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
C911 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
C912 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
C913 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
C915 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
C916 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
C918 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
C919 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
C920 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C921 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C922 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C923 1-165-492-21 ELECT CHIP 100uF 20% 10V
C924 1-165-492-21 ELECT CHIP 100uF 20% 10V
C925 1-165-492-21 ELECT CHIP 100uF 20% 10V
C926 1-165-492-21 ELECT CHIP 100uF 20% 10V
C927 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C928 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C1020 1-100-245-21 CERAMIC CHIP 0.001uF 10% 250V
C1021 1-100-245-21 CERAMIC CHIP 0.001uF 10% 250V
C1022 1-100-245-21 CERAMIC CHIP 0.001uF 10% 250V
C1023 1-100-245-21 CERAMIC CHIP 0.001uF 10% 250V
C1024 1-100-245-21 CERAMIC CHIP 0.001uF 10% 250V
C1025 1-100-245-21 CERAMIC CHIP 0.001uF 10% 250V
C1030 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C1031 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C1032 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C1033 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C1034 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1035 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1036 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1037 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1038 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1039 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1041 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1042 1-216-295-91 SHORT CHIP 0
C1043 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1044 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1045 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1046 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
C1047 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
C1048 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
C1049 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
C1050 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
C1051 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
C1054 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
C1055 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
C1056 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
C1057 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
C1058 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
C1059 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
C1060 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1061 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1062 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1063 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1064 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1065 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1089 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C1093 1-112-692-11 CERAMIC CHIP 1000PF 5% 50V
C1094 1-112-692-11 CERAMIC CHIP 1000PF 5% 50V
C1095 1-112-692-11 CERAMIC CHIP 1000PF 5% 50V
C1096 1-112-692-11 CERAMIC CHIP 1000PF 5% 50V
C1097 1-112-692-11 CERAMIC CHIP 1000PF 5% 50V
C1098 1-112-692-11 CERAMIC CHIP 1000PF 5% 50V
C1101 1-117-681-11 ELECT CHIP 100uF 20% 16V
C1102 1-112-806-11 ELECT CHIP 47uF 20% 50V
C1103 1-112-806-11 ELECT CHIP 47uF 20% 50V
C1107 1-112-795-11 ELECT CHIP 22uF 20% 25V
C1108 1-114-236-21 CERAMIC CHIP 22uF 10% 25V
C1109 1-114-236-21 CERAMIC CHIP 22uF 10% 25V
C1110 1-114-236-21 CERAMIC CHIP 22uF 10% 25V
C1111 1-114-236-21 CERAMIC CHIP 22uF 10% 25V
C1112 1-114-236-21 CERAMIC CHIP 22uF 10% 25V
C1113 1-114-236-21 CERAMIC CHIP 22uF 10% 25V
C1114 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
C1115 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
C1116 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
C1117 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
C1118 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
C1119 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
C1120 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
C1121 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
C1122 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
C1123 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
C1124 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
C1125 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
C1136 1-114-920-21 CERAMIC CHIP 0.47uF 10% 250V
C1137 1-114-920-21 CERAMIC CHIP 0.47uF 10% 250V
C1138 1-114-920-21 CERAMIC CHIP 0.47uF 10% 250V
C1139 1-114-920-21 CERAMIC CHIP 0.47uF 10% 250V
C1140 1-114-920-21 CERAMIC CHIP 0.47uF 10% 250V
C1141 1-114-920-21 CERAMIC CHIP 0.47uF 10% 250V
C1150 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C1151 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C1152 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C1153 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C1154 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C1155 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C1156 1-118-626-11 ELECT 4700uF 20% 71V
C1157 1-118-626-11 ELECT 4700uF 20% 71V
C1158 1-118-626-11 ELECT 4700uF 20% 71V
C1159 1-118-626-11 ELECT 4700uF 20% 71V
C1160 1-118-626-11 ELECT 4700uF 20% 71V
C1161 1-118-626-11 ELECT 4700uF 20% 71V
C1164 1-118-118-91 CERAMIC CHIP 0.22uF 10% 100V
MOTHERBOARD
Ver. 1.2
