Sony HCD-SHAKE7 - Electrical Parts List - Motherboard Resistors (Continued); Motherboard Resistor List (Part 4)

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKE7
84
R754 1-218-965-11 METAL CHIP 10K 5% 1/16W
R755 1-218-965-11 METAL CHIP 10K 5% 1/16W
R756 1-218-965-11 METAL CHIP 10K 5% 1/16W
R775 1-218-973-11 METAL CHIP 47K 5% 1/16W
R776 1-218-973-11 METAL CHIP 47K 5% 1/16W
R777 1-218-973-11 METAL CHIP 47K 5% 1/16W
R778 1-218-973-11 METAL CHIP 47K 5% 1/16W
R779 1-218-973-11 METAL CHIP 47K 5% 1/16W
R780 1-218-973-11 METAL CHIP 47K 5% 1/16W
R781 1-218-973-11 METAL CHIP 47K 5% 1/16W
R782 1-218-973-11 METAL CHIP 47K 5% 1/16W
R783 1-218-973-11 METAL CHIP 47K 5% 1/16W
R784 1-218-973-11 METAL CHIP 47K 5% 1/16W
R785 1-218-973-11 METAL CHIP 47K 5% 1/16W
R786 1-218-973-11 METAL CHIP 47K 5% 1/16W
R787 1-218-973-11 METAL CHIP 47K 5% 1/16W
R788 1-218-973-11 METAL CHIP 47K 5% 1/16W
R807 1-218-973-11 METAL CHIP 47K 5% 1/16W
R808 1-218-973-11 METAL CHIP 47K 5% 1/16W
R809 1-218-973-11 METAL CHIP 47K 5% 1/16W
R810 1-218-973-11 METAL CHIP 47K 5% 1/16W
R812 1-218-990-81 SHORT CHIP 0
R813 1-218-990-81 SHORT CHIP 0
R814 1-218-990-81 SHORT CHIP 0
R816 1-218-990-81 SHORT CHIP 0
R817 1-218-990-81 SHORT CHIP 0
R818 1-218-990-81 SHORT CHIP 0
R819 1-218-990-81 SHORT CHIP 0
R820 1-216-296-11 SHORT CHIP 0
R821 1-218-990-81 SHORT CHIP 0
R822 1-218-990-81 SHORT CHIP 0
R823 1-218-990-81 SHORT CHIP 0
R824 1-216-296-11 SHORT CHIP 0
R825 1-218-990-81 SHORT CHIP 0
R826 1-218-990-81 SHORT CHIP 0
R827 1-218-990-81 SHORT CHIP 0
R828 1-216-801-11 METAL CHIP 22 5% 1/10W
R829 1-218-953-11 METAL CHIP 1K 5% 1/16W
R830 1-218-953-11 METAL CHIP 1K 5% 1/16W
R831 1-218-955-11 METAL CHIP 1.5K 5% 1/16W
R832 1-218-955-11 METAL CHIP 1.5K 5% 1/16W
R901 1-216-809-11 METAL CHIP 100 5% 1/10W
R902 1-216-809-11 METAL CHIP 100 5% 1/10W
R903 1-216-833-11 METAL CHIP 10K 5% 1/10W
R904 1-216-833-11 METAL CHIP 10K 5% 1/10W
R905 1-216-833-11 METAL CHIP 10K 5% 1/10W
R906 1-216-833-11 METAL CHIP 10K 5% 1/10W
R908 1-216-833-11 METAL CHIP 10K 5% 1/10W
R916 1-216-833-11 METAL CHIP 10K 5% 1/10W
R917 1-216-833-11 METAL CHIP 10K 5% 1/10W
R918 1-216-835-11 METAL CHIP 15K 5% 1/10W
R919 1-216-838-11 METAL CHIP 27K 5% 1/10W
R920 1-216-838-11 METAL CHIP 27K 5% 1/10W
R921 1-216-841-11 METAL CHIP 47K 5% 1/10W
R922 1-216-841-11 METAL CHIP 47K 5% 1/10W
R923 1-216-845-11 METAL CHIP 100K 5% 1/10W
R924 1-216-845-11 METAL CHIP 100K 5% 1/10W
R925 1-216-864-11 SHORT CHIP 0
R926 1-216-864-11 SHORT CHIP 0
R927 1-257-362-21 METAL CHIP 1 5% 1/2W
* R928 1-250-572-11 METAL CHIP 15 1% 1/10W
* R929 1-250-572-11 METAL CHIP 15 1% 1/10W
* R930 1-250-572-11 METAL CHIP 15 1% 1/10W
* R931 1-250-572-11 METAL CHIP 15 1% 1/10W
* R932 1-250-572-11 METAL CHIP 15 1% 1/10W
* R933 1-250-572-11 METAL CHIP 15 1% 1/10W
R1000 1-218-857-11 METAL CHIP 2.7K 0.5% 1/10W
R1001 1-218-857-11 METAL CHIP 2.7K 0.5% 1/10W
R1002 1-218-857-11 METAL CHIP 2.7K 0.5% 1/10W
R1003 1-218-857-11 METAL CHIP 2.7K 0.5% 1/10W
R1004 1-218-857-11 METAL CHIP 2.7K 0.5% 1/10W
R1005 1-218-857-11 METAL CHIP 2.7K 0.5% 1/10W
R1006 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R1007 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R1008 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R1009 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R1010 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R1011 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R1012 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R1013 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R1014 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R1015 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R1016 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R1017 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R1018 1-218-865-11 METAL CHIP 5.6K 0.5% 1/10W
R1019 1-218-865-11 METAL CHIP 5.6K 0.5% 1/10W
R1020 1-218-865-11 METAL CHIP 5.6K 0.5% 1/10W
R1021 1-208-905-11 METAL CHIP 5.6K 0.5% 1/16W
R1022 1-208-905-11 METAL CHIP 5.6K 0.5% 1/16W
R1023 1-208-905-11 METAL CHIP 5.6K 0.5% 1/16W
R1024 1-208-905-11 METAL CHIP 5.6K 0.5% 1/16W
R1025 1-218-865-11 METAL CHIP 5.6K 0.5% 1/10W
R1026 1-208-905-11 METAL CHIP 5.6K 0.5% 1/16W
R1027 1-218-865-11 METAL CHIP 5.6K 0.5% 1/10W
R1028 1-208-905-11 METAL CHIP 5.6K 0.5% 1/16W
R1029 1-218-865-11 METAL CHIP 5.6K 0.5% 1/10W
R1030 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R1031 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R1032 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R1033 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R1034 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R1035 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R1040 1-216-296-11 SHORT CHIP 0
R1041 1-216-296-11 SHORT CHIP 0
R1042 1-216-296-11 SHORT CHIP 0
R1043 1-216-296-11 SHORT CHIP 0
R1044 1-216-296-11 SHORT CHIP 0
R1045 1-216-296-11 SHORT CHIP 0
R1046 1-216-796-11 METAL CHIP 8.2 5% 1/10W
R1047 1-216-796-11 METAL CHIP 8.2 5% 1/10W
R1048 1-216-796-11 METAL CHIP 8.2 5% 1/10W
R1050 1-216-864-11 SHORT CHIP 0
R1051 1-216-864-11 SHORT CHIP 0
R1052 1-216-864-11 SHORT CHIP 0
R1053 1-216-864-11 SHORT CHIP 0
R1054 1-216-864-11 SHORT CHIP 0
R1055 1-216-864-11 SHORT CHIP 0
R1056 1-216-864-11 SHORT CHIP 0
R1057 1-216-864-11 SHORT CHIP 0
R1058 1-216-864-11 SHORT CHIP 0
MOTHERBOARD
Ver. 1.2
