Sony HCD-SHAKE7 - Electrical Parts List - Volume Board (Continued); Volume Board Miscellaneous Parts List

Ref. No. Part No. Description Remark
HCD-SHAKE7
90
R2737 1-216-812-11 METAL CHIP 180 5% 1/10W
R2738 1-216-812-11 METAL CHIP 180 5% 1/10W
R2739 1-216-812-11 METAL CHIP 180 5% 1/10W
R2740 1-216-812-11 METAL CHIP 180 5% 1/10W
R2741 1-216-812-11 METAL CHIP 180 5% 1/10W
R2742 1-216-812-11 METAL CHIP 180 5% 1/10W
< SWITCH >
S2601 1-786-417-11 ENCODER, ROTARY (VOLUME / DJ CONTROL)
*************************************************************
MISCELLANEOUS
**************
0 51 1-855-006-41 FAN, DC
102 1-828-299-21 WIRE (FLAT TYPE) (7 CORE)
103 1-829-321-21 WIRE (FLAT TYPE) (17 CORE)
104 1-828-393-21 WIRE (FLAT TYPE) (25 CORE)
105 1-828-308-21 WIRE (FLAT TYPE) (9 CORE)
107 1-500-082-11 CLAMP, SLEEVE FERRITE
110 8-989-470-00 RC-S801/A (WW)
111 1-828-693-21 WIRE (FLAT TYPE) (8 CORE)
112 1-490-558-32 BLUETOOTH MODULE
113 1-828-722-21 WIRE (FLAT TYPE) (14 CORE)
0 154 1-474-485-11 REGULATOR, SWITCHING (SMG-1800)
155 1-457-369-12 CORE, FERRITE
0 157 1-835-706-22 CORD, POWER-SUPPLY (E51)
0 157 1-837-312-11 CORD, POWER-SUPPLY (AR)
0 157 1-837-344-11 CORD, POWER-SUPPLY (E2, MX)
0 157 1-838-939-11 CORD, POWER (SAF, E4)
0 157 1-839-999-21 POWER-SUPPLY CORD (EA, MY)
0 158 1-569-007-31 ADAPTOR, CONVERSION 2P (E2)
0 158 1-785-504-21 ADAPTOR, CONVERSION (E51)
0 158 1-843-324-11 ADAPTOR, CONVERSION 2P (E4)
201 A-1896-391-A LOADING COMPLETE ASSY (T)
(including MS-476 board)
0 204 A-1940-584-A SERVICE, OPTICAL DEVICE (for SERVICE)
205 1-828-292-21 WIRE (FLAT TYPE) (5 CORE)
206 1-830-282-21 WIRE (FLAT TYPE) (24 CORE)
S2601 1-786-417-11 ENCODER, ROTARY (VOLUME / DJ CONTROL)
Ver. 1.2
Note: If wire (fl at type) is replaced, install it after bending it in the
same form as that before replacement.
VOLUME
