Sony HCD-V4800 - Page 25

– 25 –
Pin No. Pin Name I/O Function
87 PB-A/B O
Deck-A/B selection signal output to the HA12203NT (IC1501) “L”: deck-A, “H”: deck-B
88 EQ-H/N O
Normal/high speed selection signal output to the HA12203NT (IC1501)
“L”: normal speed, “H”: high speed
89 BIAS O
Recording bias on/off selection signal output to the HA12203NT (IC1501)
“L”: bias off, “H”: bias on
90 REC-MUTE O
Recording mute on/off selection signal output to the HA12203NT (IC1501)
“L”: mute on, “H”: mute off
91 NR-ON/OFF O
Dolby NR on/off selection signal output to the HA12203NT (IC1501)
“L”: dolby off, “H”: dolby on
92 R/P-PASS O
Recording/playback/pass selection signal output to the HA12203NT (IC1501)
93 TC-MUTE O
Line mute on/off selection signal output to the HA12203NT (IC1501)
“L”: mute off, “H”: mute on
94 A-PLAY-SW I
Detection input from the deck- A play detect switch (S1001) “H”: deck-A play
95 B-PLAY-SW I
Detection input from the deck- B play detect switch (S1002) “H”: deck-B play
96 RELAY O
Recording/playback select signal output to the REC/PB switch (IC602)
“L”: playback, “H”: recording
97 A-HALF I
Detection input from the deck-A cassette detect switch (S1004)
“L”: cassette in, “H”: no cassette
98 POWER O
On/off selection signal output of the main power supply “L”: power on
99 SW-F-CON O
Control signal output of the super woofer mode “H”: music, “L”: movie
100 STK-MUTE O
Power amplifier on/off selection signal output terminal “L”: on, “H”: standby
