Sony HCD-V4800 - 1 General; Location of Controls; Front Panel

– 4 –
1 POWER button
2 SPECTRUM ANALYZER button
3 DISPLAY/DEMO button
4 Remote control receiver
5 Fluorescent indicator tube
6 EFFECT button and indicator
7 ENTER/NEXT button and indicator
8 TUNER MEMORY button
9 TUNING MODE button
0 TUNING – button
!¡ TUNER/BAND button and indicator
!™ TUNING + button
!£ STEREO/MONO button
!¢ FUNCTION button
!∞ VOLUME control knob
!§ SUPER WOOFER button and indicator
!¶ SUPER W MODE button
!• p button (deck B side)
!ª ) button (deck B side)
@º 0 button (deck B side)
@¡ § EJECT button (deck B side)
@™ 6 OPEN button
@£ t /CLOCK SET button
@¢ SLEEP button
@∞ REC button
@§ ) button (deck A side)
@¶ p button (deck A side)
@• 0 button (deck A side)
@ª § EJECT button (deck A side)
#º DIRECT PLAY DISC 1 to DISC 5 buttons
#¡ ˆ RETURN button
#™ PREV button
#£ NEXT button
#¢ Cassette holder (deck A side)
#∞ CD disc tray
#§ Cassette holder (deck B side)
#¶ 0 button
#• ≠ AMS ± jog dial knob
#ª ) button
SECTION 1
GENERAL
LOCATION OF CONTROLS
— Front Panel —
0
!¡
9
8
7
65
4321
!™
!£
!¢
!∞
!§
!¶
!•
!ª
@º
@¡
@™
@£
@¢
@∞
@§
@¶
@•
@ª
#º
#¡ #™
#£ #¢ #∞ #§
#¶
#• #ª
