Sony HCD-V4800 - Rear Panel Layout and Time Setting

– 6 –
1 FM ANTENNA terminal
2 AM ANTENNA terminal
3 VOLTAGE SELECTOR (except Malaysia, Thai models)
4 PHONO IN pin jack
5 VIDEO (AUDIO) IN pin jack
6 VIDEO (AUDIO) OUT pin jack
7 SPEAKER output terminal
8 VIDEO OUT pin jack
9 S VIDEO OUT connector
0 SYSTEM SELECT switch (NTSC/AUTO/PAL select)
— Rear Panel —
12
3
4
5
6
7
8
90
