– 31 –
Pin No. Pin Name I/O Function
68 NR-XCS O
Chip select signal output to the video noise reduction (IC301)
69 P54 I
Not used (fixed at “L”)
70 P55 I
Not used (fixed at “L”)
71 VSS —
Ground terminal
72 P56 I
Not used (fixed at “L”)
73 P57 I
Not used (fixed at “L”)
74 to 81 P60 to P67 I
Not used (fixed at “L”)
82 to 85 P100 to P103 I
Not used (fixed at “L”)
86 to 93 P30 to P37 I
Not used (fixed at “L”)
94 to 100 P150 to P156 I
Not used (fixed at “L”)
