• Waveforms
– BD Section –
1 IC101 @§ (RFDC) 200 mV/DIV, 500 ns/DIV
2 IC101 @¶ (TE) 200 mV/DIV, 100 µs/DIV
3 IC101 @ª (FE) 200 mV/DIV, 50 ns/DIV
Approx. 200 mVp-p
4 IC101 #§ (RFAC) 200 mV/DIV, 500 ns/DIV
5 IC101 $∞ (LRCK)
6 IC101 $¶ (BCLK)
7 IC101 ^™ (XTAI)
5.2 Vp-p
16.9344 MHz
8 IC101 (§ (MDP)
2.6 Vp-p
7.5
µ
s
– VIDEO Section –
1 IC501 !§ (B3 (384FS))
4.4 Vp-p
16.9344 MHz
2 IC501 9 (A8 (BCLK))
4.6 Vp-p
474 ns
3 IC501 7 (A6 (LRCK))
5.2 Vp-p
22.7 µ s
4 IC701 %¡ (EXTAL)
5 Vp-p
10 MHz
5 IC201 2 (XTL0O)
2.5 Vp-p
28.63636 MHz
5.2 Vp-p
474 ns
