Sony HCD-V4800 - Page 40

– 87 –
@¡ IC901 !º (X2)
@™ IC101 6 (384FSO)
@£ IC101 !º (BCK)
@¢ IC101 !™ (LRCK)
@∞ IC101 @™ (XIN)
1 IC301 !¡ (X1)
2 IC301 !¢ (XT1)
– PANEL Section –
1 IC601 8 (X-OUT)
5.4 Vp-p
5 MHz
3.1 Vp-p
16.9344 MHz
5 Vp-p
474 ns
5 Vp-p
22.7
µ
s
520 mVp-p
Note:
1. When pin %ª (TEST0) of IC701 (mechanism controller) on the VIDEO board is connected to ground.
(A solder bridge of SL701 is shorted.)
2.1 Vp-p
8 MHz
3.1 Vp-p
32.768 kHz
4.4 Vp-p
5 MHz
– MAIN Section –
