Sony HCD-VX3A - Page 79

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
79
< DIODE >
D301 8-719-054-23 DIODE RB706D-40-T146
D501 8-719-422-12 DIODE UDZ-TE-17-3.9B
D502 8-719-018-51 DIODE CL-170R-CD-T
< IC >
IC101 8-759-701-39 IC NJM2100M(TE2)
IC401 8-759-262-00 IC MC14576CFEL
IC501 8-759-269-92 IC SN74HCU04ANSR
IC502 8-759-587-67 IC M30620MC-A05FP
IC504 8-759-269-92 IC SN74HCU04ANSR
IC505 8-759-535-48 IC CL680T-D1
IC506 8-759-573-23 IC LC372100PM-J48-TLA
IC507 8-759-342-01 IC MSM514260C-60JS
IC509 8-759-535-62 IC PCM1727E-2/T2
< JACK >
J301 1-537-943-11 TERMINAL, S (S VIDEO OUT)
J302 1-774-227-11 JACK, PIN 1P (VIDEO OUT)
< JUMPER RESISTOR >
JW101 1-216-295-91 SHORT 0
JW201 1-216-295-91 SHORT 0
JW401 1-216-295-91 SHORT 0
JW402 1-216-295-91 SHORT 0
JW403 1-216-295-91 SHORT 0
JW404 1-216-295-91 SHORT 0
JW405 1-216-295-91 SHORT 0
JW413 1-216-295-91 SHORT 0
JW421 1-216-295-91 SHORT 0
JW422 1-216-295-91 SHORT 0
JW503 1-216-295-91 SHORT 0
JW504 1-216-295-91 SHORT 0
JW505 1-216-295-91 SHORT 0
< COIL >
L301 1-410-372-21 INDUCTOR CHIP 1.8uH
L302 1-410-372-21 INDUCTOR CHIP 1.8uH
L501 1-216-296-91 SHORT 0
L502 1-216-296-91 SHORT 0
L503 1-216-296-91 SHORT 0
L504 1-410-375-11 INDUCTOR CHIP 3.3uH
L505 1-216-296-91 SHORT 0
L506 1-216-296-91 SHORT 0
L507 1-216-296-91 SHORT 0
L508 1-216-296-91 SHORT 0
L509 1-216-296-91 SHORT 0
L510 1-216-296-91 SHORT 0
< TRANSISTOR >
Q301 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q302 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q303 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q304 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q306 8-729-027-44 TRANSISTOR DTC114TKA-T146
Q307 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q308 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q310 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q453 8-729-920-72 TRANSISTOR 2SA1037K-T-146-QR
Q454 8-729-920-72 TRANSISTOR 2SA1037K-T-146-QR
Q502 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q531 8-729-140-75 TRANSISTOR 2SD999-T1-CLCK
< RESISTOR >
R101 1-216-073-00 METAL CHIP 10K 5% 1/10W
R102 1-208-441-61 RES,CHIP 1.5K 2% 1/10W
R103 1-208-441-61 RES,CHIP 1.5K 2% 1/10W
R105 1-216-295-91 SHORT 0
R201 1-216-073-00 METAL CHIP 10K 5% 1/10W
R202 1-208-441-61 RES,CHIP 1.5K 2% 1/10W
R203 1-208-441-61 RES,CHIP 1.5K 2% 1/10W
R205 1-216-295-91 SHORT 0
R301 1-216-624-11 METAL CHIP 75 0.5% 1/10W
R302 1-216-624-11 METAL CHIP 75 0.5% 1/10W
R305 1-216-049-91 RES,CHIP 1K 5% 1/10W
R306 1-216-073-00 METAL CHIP 10K 5% 1/10W
R307 1-216-049-91 RES,CHIP 1K 5% 1/10W
R308 1-216-049-91 RES,CHIP 1K 5% 1/10W
R309 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R312 1-216-073-00 METAL CHIP 10K 5% 1/10W
R313 1-216-049-91 RES,CHIP 1K 5% 1/10W
R314 1-216-049-91 RES,CHIP 1K 5% 1/10W
R315 1-216-047-91 RES,CHIP 820 5% 1/10W
R316 1-216-657-11 METAL CHIP 1.8K 0.5% 1/10W
R317 1-216-683-11 METAL CHIP 22K 0.5% 1/10W
R318 1-216-033-00 METAL CHIP 220 5% 1/10W
R319 1-216-049-91 RES,CHIP 1K 5% 1/10W
R320 1-216-651-11 METAL CHIP 1K 0.5% 1/10W
R321 1-216-049-91 RES,CHIP 1K 5% 1/10W
R324 1-216-022-00 METAL CHIP 75 5% 1/10W
R325 1-216-295-91 SHORT 0
R327 1-216-049-91 RES,CHIP 1K 5% 1/10W
R328 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R329 1-216-649-11 METAL CHIP 820 0.5% 1/10W
R332 1-216-651-11 METAL CHIP 1K 0.5% 1/10W
R333 1-216-046-00 METAL CHIP 750 5% 1/10W
R335 1-216-073-00 METAL CHIP 10K 5% 1/10W
R336 1-216-073-00 METAL CHIP 10K 5% 1/10W
R340 1-216-022-00 METAL CHIP 75 5% 1/10W
R341 1-216-121-91 RES,CHIP 1M 5% 1/10W
R342 1-216-022-00 METAL CHIP 75 5% 1/10W
R403 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R404 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R405 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R406 1-216-081-00 METAL CHIP 22K 5% 1/10W
R407 1-216-073-00 METAL CHIP 10K 5% 1/10W
R408 1-216-073-00 METAL CHIP 10K 5% 1/10W
R409 1-216-049-91 RES,CHIP 1K 5% 1/10W
R410 1-216-049-91 RES,CHIP 1K 5% 1/10W
R411 1-216-073-00 METAL CHIP 10K 5% 1/10W
R412 1-216-073-00 METAL CHIP 10K 5% 1/10W
R414 1-216-081-00 METAL CHIP 22K 5% 1/10W
R415 1-216-081-00 METAL CHIP 22K 5% 1/10W
R423 1-216-073-00 METAL CHIP 10K 5% 1/10W
VIDEO
