Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
80
R424 1-216-073-00 METAL CHIP 10K 5% 1/10W
R425 1-216-073-00 METAL CHIP 10K 5% 1/10W
R426 1-216-073-00 METAL CHIP 10K 5% 1/10W
R457 1-216-025-91 RES,CHIP 100 5% 1/10W
R458 1-216-025-91 RES,CHIP 100 5% 1/10W
R459 1-216-025-91 RES,CHIP 100 5% 1/10W
R461 1-216-025-91 RES,CHIP 100 5% 1/10W
R462 1-216-025-91 RES,CHIP 100 5% 1/10W
R463 1-216-025-91 RES,CHIP 100 5% 1/10W
R464 1-216-025-91 RES,CHIP 100 5% 1/10W
R501 1-216-025-91 RES,CHIP 100 5% 1/10W
R502 1-216-025-91 RES,CHIP 100 5% 1/10W
R503 1-216-025-91 RES,CHIP 100 5% 1/10W
R504 1-216-025-91 RES,CHIP 100 5% 1/10W
R505 1-216-025-91 RES,CHIP 100 5% 1/10W
R506 1-216-025-91 RES,CHIP 100 5% 1/10W
R507 1-216-073-00 METAL CHIP 10K 5% 1/10W
R508 1-216-081-00 METAL CHIP 22K 5% 1/10W
R509 1-216-081-00 METAL CHIP 22K 5% 1/10W
R510 1-216-081-00 METAL CHIP 22K 5% 1/10W
R511 1-216-081-00 METAL CHIP 22K 5% 1/10W
R512 1-216-081-00 METAL CHIP 22K 5% 1/10W
R513 1-216-081-00 METAL CHIP 22K 5% 1/10W
R514 1-216-081-00 METAL CHIP 22K 5% 1/10W
R516 1-216-073-00 METAL CHIP 10K 5% 1/10W
R517 1-216-073-00 METAL CHIP 10K 5% 1/10W
R518 1-216-073-00 METAL CHIP 10K 5% 1/10W
R519 1-216-025-91 RES,CHIP 100 5% 1/10W
R520 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R523 1-216-013-00 METAL CHIP 33 5% 1/10W
R530 1-216-081-00 METAL CHIP 22K 5% 1/10W
R531 1-216-025-91 RES,CHIP 100 5% 1/10W
R532 1-216-025-91 RES,CHIP 100 5% 1/10W
R533 1-216-025-91 RES,CHIP 100 5% 1/10W
R534 1-216-073-00 METAL CHIP 10K 5% 1/10W
R535 1-216-073-00 METAL CHIP 10K 5% 1/10W
R536 1-216-033-00 METAL CHIP 220 5% 1/10W
R537 1-216-025-91 RES,CHIP 100 5% 1/10W
R538 1-216-073-00 METAL CHIP 10K 5% 1/10W
R542 1-216-049-91 RES,CHIP 1K 5% 1/10W
R543 1-216-685-11 METAL CHIP 27K 0.5% 1/10W
R544 1-216-659-11 METAL CHIP 2.2K 0.5% 1/10W
R545 1-216-025-91 RES,CHIP 100 5% 1/10W
R546 1-216-049-91 RES,CHIP 1K 5% 1/10W
R547 1-216-295-91 SHORT 0
R548 1-216-049-91 RES,CHIP 1K 5% 1/10W
R549 1-216-025-91 RES,CHIP 100 5% 1/10W
R550 1-216-025-91 RES,CHIP 100 5% 1/10W
R551 1-216-025-91 RES,CHIP 100 5% 1/10W
R552 1-216-025-91 RES,CHIP 100 5% 1/10W
R554 1-216-025-91 RES,CHIP 100 5% 1/10W
R555 1-216-121-91 RES,CHIP 1M 5% 1/10W
R556 1-216-025-91 RES,CHIP 100 5% 1/10W
R557 1-216-025-91 RES,CHIP 100 5% 1/10W
R558 1-216-073-00 METAL CHIP 10K 5% 1/10W
R559 1-216-073-00 METAL CHIP 10K 5% 1/10W
R560 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R561 1-216-049-91 RES,CHIP 1K 5% 1/10W
R562 1-216-025-91 RES,CHIP 100 5% 1/10W
R563 1-216-025-91 RES,CHIP 100 5% 1/10W
R564 1-216-025-91 RES,CHIP 100 5% 1/10W
R565 1-216-025-91 RES,CHIP 100 5% 1/10W
R566 1-216-025-91 RES,CHIP 100 5% 1/10W
R567 1-216-073-00 METAL CHIP 10K 5% 1/10W
R568 1-216-073-00 METAL CHIP 10K 5% 1/10W
R569 1-216-073-00 METAL CHIP 10K 5% 1/10W
R572 1-216-073-00 METAL CHIP 10K 5% 1/10W
R573 1-216-073-00 METAL CHIP 10K 5% 1/10W
R574 1-216-073-00 METAL CHIP 10K 5% 1/10W
R577 1-216-081-00 METAL CHIP 22K 5% 1/10W
R578 1-216-081-00 METAL CHIP 22K 5% 1/10W
R579 1-216-073-00 METAL CHIP 10K 5% 1/10W
R580 1-216-073-00 METAL CHIP 10K 5% 1/10W
< SWITCH >
S501 1-571-395-11 SWITCH, SLIDE (SYSTEM SELECT)
< VIBRATOR >
X501 1-767-510-41 VIBRATOR, CERAMIC 10.0MHz
X503 1-767-519-11 VIBRATOR, CRYSTAL 27.0MHz
***********************************************************
**************
MISCELLANEOUS
**************
6 1-773-120-11 WIRE(FLAT TYPE) (19 CORE)
10 1-773-043-11 WIRE(FLAT TYPE)(17 CORE)
11 1-773-024-11 WIRE(FLAT TYPE)(15 CORE)
106 1-775-212-11 WIRE(FLAT TYPE) (23 CORE)
(EA,E,JE,MY,SP,TW)
109 1-233-546-11 TUNER(FM/MW/SW)(EA,E,JE,MY,SP,TW,TH)
109 1-233-545-14 ENCAPSULATED COMPONENT (TH)
112 1-690-589-31 WIRE(FLAT TYPE) (13 CORE)
! 114 1-575-653-11 CORD, POWER (EXCEPT EA)
! 114 1-777-071-21 CORD, POWER (EA)
! 115 1-569-007-11 ADAPTOR, CONVERSION 2P (JE/IA)
! 115 1-569-008-21 ADAPTOR, CONVERSION 2P (EA)
257 1-452-925-21 MAGNET ASSY
* 257 1-452-879-11 MAGNET(EA,E,JE,MY,SP,TW,TH)
! 301 8-820-020-02 OPTICAL PICK-UP KSS-213D/Q-RP
302 1-769-069-11 WIRE (FLAT TYPE)(16 CORE)
M101 X-4917-523-4 MOTOR ASSY (SPINDLE)
M102 X-4917-504-1 MOTOR ASSY (SLED)
! T11 1-433-902-11 TRANSFORMER, POWER
S811 1-473-335-11 ENCODER, ROTARY
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
