Sony HCD-VX88 - Page 24

HCD-VX88
24
24
Waveforms
– CD SECTION – – VIDEO SECTION –
– MAIN BOARD –
1 IC601 oa
STOP MODE
4.8Vp-p
12.5MHz
– PANEL BOARD –
1 IC101 t;
RFAC
2 IC101 ra
TE
3 IC101 el
FE
4 IC101 wg
MDP
1.3Vp-p
APPROX 500mVp-p
2.5V
APPROX 200mVp-p
2.5V
2.6Vp-p
7.5µsec
1 IC502 qd
XOUT
2 IC505 ug
COUT
3 IC505 yl
YOUT
4 IC304 9
COUT
5 IC304 qg
YOUT
6 IC509 1
XT1
7 IC509 ql
LRCK
8 IC509 qj
BCK
9 IC504 8
384FS
q; IC504 6
27M
4Vp-p
10MHz
H
1Vp-p
H
1Vp-p
2Vp-p
H
2Vp-p
H
27MHz
5.8Vp-p
4.6Vp-p
44.1kHz
4.8Vp-p
2.11MHz
4.8Vp-p
33.8MHz
3.8Vp-p
27MHz
1 IC401 qa
STOP MODE
3.0Vp-p
32.768kHz
3.4Vp-p
2 IC401 qd
STOP MODE
3 T301 4
TAPE B REC MODE
16MHz
120Vp-p
80.7kHz
